Function Code Table M420 General Flux Vector Control Inverter User Manual
Function
Code
Parameter Name Setting Range Default
Property
F0-19
Command source binding
select
Unit's digit: Binding operation
keypad command to frequency
source.
0: No Binding
1:Digital setting
2: AI1
3: AI2
4: Multi-speed
5: Simple PLC
6: PID
7: Communication setting.
8: Pulse setting(HDI5).
Ten’s digit: Binding operation
terminal command to frequency
source.
Hundred’s digit: Binding
operation communication
command to frequency source.
Thousand’s digit: Reserved.
000
☆
F0-20
Frequency fractional
selection
1: 0.1Hz
2: 0.01Hz
2
★
F0-21
Acceleration/Deceleration
time unit
0: 1s
1: 0.1s
2: 0.01s
1
★
F0-22
Acceleration/Deceleration
time base frequency
0: Maximum frequency (F0-14)
1: Set frequency
2: Rated motor frequency
0
★
F0-23 Acceleration time 1
0s
～
30000s (F0-21 = 0)
0.0s
～
3000.0s (F0-21 = 1)
0.00s
～
300.00s (F0-21 = 2)
10.0s
☆
F0-24
Deceleration time 1
0s
～
30000s (F0-21 = 0)
0.0s
～
3000.0s (F0-21 = 1)
10.0s
☆
