Chapter 11 Description of Parameter Settings|C200 Series
11-35
Settings Functions Descriptions
23
Over-voltage Stall
prevention Warning
Active when the over-voltage stall prevention is detected.
24
Operation Mode
Indication
A
ctive when the operation command is controlled by external
terminal. (Pr.00-20≠0)
25 Forward Command Active when the operation direction is forward.
26 Reverse Command Active when the operation direction is reverse.
27
Output when Current
>= Pr.02-33
Active when current is >= Pr.02-33.
28
Output when Current
<= Pr.02-33
Active when current is <= Pr.02-33.
29
Output when
frequency >=
Pr.02-34
Active when frequency is >= Pr.02-34.
30
Output when
Frequency <=
Pr.02-34
Active when frequency is <= Pr.02-34.
31
Y-connection for the
Motor Coil
Active when PR.05-24 is less than Pr.05-23 and time is more than
Pr.05-25.
32
-connection for the
Motor Coil
Active when PR.05-24 is higher than Pr.05-23 and time is more than
Pr.05-25.
33
Zero Speed (actual
output frequency)
A
ctive when the actual output frequency is 0. (the drive should be at
RUN mode)
34
Zero Speed with Stop
(actual output
frequency)
Active when the actual output frequency is 0 or Stop.
35
Error Output
Selection 1 (Pr.06-23)
Active when Pr.06-23 is ON.
36
Error Output
Selection 2 (Pr.06-24)
Active when Pr.06-24 is ON.
37
Error Output
Selection 3 (Pr.06-25)
Active when Pr.06-25 is ON.
38
Error Output
Selection 4 (Pr.06-26)
Active when Pr.06-26 is ON.
39 Reserved
40
Speed Attained
(including zero
speed)
Active when the output frequency reaches frequency setting or stop.
41 Reserved
42 Crane Function
This function should be used with Pr.02-32, Pr.02-33 and Pr.02-34.
Active when setting Pr.07-16=Pr.02-34 and Fcmd > Pr.02-34 and
output current > Pr.02-33 and Time > Pr.02-32.
The example of the crane application is in the following for your
reference.
43
Motor Zero-speed
Output (Pr.02-47)
Active when motor actual speed is less than Pr.02-47.
44 Low Current Output This function needs to be used with Pr.06-71 ~ Pr.06-73
45
Reserved
46
Master dEb signal
output
When dEb arise at Master, MO will send a dEb signal to Slave. Then
Slave will follow Master’s command and decelerate to stop
simultaneously.
47
Brake Release at
Stop
When drive stops, the corresponding multi-function terminal will be
ON if the frequency is less than Pr.02-34. After it is ON, it will be OFF
when brake delay time exceeds Pr.02-32.
