LG V-C5A43SD [5/8] Changing the air outlet filters

•Electronic power control(26)

OFF:Power off MIN:Low power

MAX:Full power

Park-System(16)

For short breaks during vacuuming, for

example to move a small piece of furniture

or a rug, use the

Park system to support

the flexible hose and cleaning head.

•

Slide the hook attached to the large cleaning

tool into the slot on the rear of the appliance.

Storage(17)

When you have switched off and unplugged

the appliance, press the button (11) to

automatically rewind the cord.

You can move or store your appliance in a

vertical position by sliding the hook on the

large cleaning head into the clip on the

underside of the appliance.

Changing the dust bag

The dustbag needs changing when the

cleaner is set to maximum power and the

cleaner head is off the floor but the

indicator window(18) is completely coloured

red.

Even if the dustbag does not appear to be

full at this stage, it should be changed, as

very fine dust can clog up the pores of the

dust bag.

• Turn off the appliance and unplug it.

• Open the cover by pressing the hook(19)

and lifting it up until it snaps into place.

Your appliance is equipped with either a

paper dust bag (20) or a fabric dust bag

(25).(depending on model)

• Take hold of the dust bag by the handle

and pull. Remove the bag and throw it

away.

• To refit a new bag push the cardboard

support of a new bag into the bag mount

(21) until it will go no further.

If your appliance is fitted with a

fabric dust bag follow the same

instructions as above.

Empty it and replace it(25). Do not wash it.

Note: as the appliance is fitted with a safety

device which checks that the bag is in place

you cannot close the lid if the bag is not

fitted correctly.

Cleaning the motor filter

The motor filter is situated inside the

appliance between the dust bag and the

motor. Each time that you change the air

outlet filter we advise you to remove the

motor filter(22) and to clean it by tapping to

remove the dirt and then replacing it in the

vacuum cleaner.

Changing the air outlet filters

Depending on the model you have chosen

your appliance is equipped with different

types of filters : foam filter or electrostatic

r(24

• To change these filters remove the cover

of the filter compartment(23) situated at

the rear of the appliance.

•The foam filter should be cleaned

regularly by tapping it to remove the dirt.

•

•Wash the washable HEPA filter with water

at least once a year.

Check that the appliance is correctly plugged

in and that the electrical socket is working.

•Stop the appliance and unplug it.

• Check that the tubes, flexible hose and

cleaning tool are not blocked.

•Check that the dust bag is not full.Replace

if necessary.

•Check that the air outlet filter is not

blocked. Replace if necessary.

What to do if your appliance

does not work?

What to do when the suction

performance reduces?

"bag full"
