ZSM 130
MEASUREMENT FOUNDATION
30
Measurement Preparation
1. Battery loading
Remove the battery cover on the back and put in one 9V Battery.
2. Battery Replacement
When the battery voltage drops below the operating voltage, appears. If it appears, battery should
be replaced with new one.
Precautions
Wind blowing across the microphone would bring additional extraneous noise.Once using the instrument in the
presence of wind, it is a must to mount the windscreen to not pick up undesirable signals.
Calibrate the instrument before operation if the instrument was not in use for a long time or operated at bad envi-
ronment.
Do not store or operate the instrument at high temperature and high humidity environment.
Keep microphone dry and avoid severe vibration.
Please take the battery and keep the instrument in low humidity environment. When not in use.
Measurement
Open battery cover and install a 9-volt battery in the battery compartment.
Turn on power and select the desired response Time and weighting. If the sound source consists of short bursts
or only catching sound peak, set response to FAST. To measure average sound, use the slow setting.Select A-
weighting for general noise sound level and C-weighting for measuring sound level of acoustic material.
1.
2.
3.
4.
5.
1.
2.
