LG V-C5761HT [5/12] Cleaning the motor filter

– 5 –

support the flexible hose and cleaning

head.

• Slide the hook attached to the large

cleaning tool into the slot on the rear of

the appliance.

Carring and storage (15)

When you have switched off and

unplugged the appliance, press on the

button (12) to automatically rewind the

cord.

You can move or store your appliance in

a vertical position by sliding the hook on

the large cleaning head into the clip on

the underside of the appliance.

Changing the dust bag

The dustbag needs changing when the

cleaner is set to maximum power and the

cleaner head is off the floor but the "bag

full" LED (red)(16) shine.

When the bag is full lamp(Red) is on.

also, it(cleaner) makes suction power low

rapidly by itself to protect the motor after

1 and half minute.

This time bag full lamp(Red) is still on.

Even if the dustbag does not appear to be

full at this stage, it should be changed.

It could be that a great deal of very fine

dust has clogged up the pores of the dust

bag.

• Turn off the appliance and unplug it.

• Open the cover by pulling the cover(17).

• Pull out the filter bag carrier.

• Push the latch (18) forwards in the

direction of the arrow and remove the

full dust bag throw it away.

• Insert the new dust bag into the

cleaner(19).

Note: as the appliance is fitted with a

safety device which checks that the bag is

in place you cannot colse the cover if the

bag is not fitted correctly.

Cleaning the motor filter

The motor filter is situated inside the

appliance between the dust bag and the

motor. Each time that you change the air

outlet filter we advise you to remove the

motor filter (20) and to clean it by tapping

to remove the dirt and then replacing it in

the vacuum cleaner.

Changing the air outlet filters

• To change filter (21) remove the cover

of the filter compartment (22) situated at

the rear of the appliance, by pushing the

little catch.

Crevice Tool (23)

For vacuuming in those normally inaccess-

ible places i.e. reaching cobwebs, or down

the side of a sofa! Set the suction power

control switch to sofa before vacuuming

Dusting brush (24)

For vacuuming picture frames furniture

outlines, books and other uneven objects.

Upholstery Nozzle (25)

For vacuuming uphostery, mattresses, etc.

The thread collectors help to pick up the

threads and fluff.

Check that the appliance is correctly

plugged in and that the electrical socket is

working.

• Stop the appliance and unplug it.

• Check that the tubes, flexible hose and

cleaning tool are not blocked.

• Check that the dust bag is not full.

Replace it if necessary.

• Check that the air outlet filter is not

blocked. Replace it if necessary.

What to do if your appliance

does not work

What to do when the suction

performance reduces?
