Galletti MPI DC 029 [3/6] Air chillers and heat pumps mpi dc
![Galletti MPI DC 014 [3/6] Air chillers and heat pumps mpi dc](/views2/1572322/page3/bg3.png)
148
galletti.com VM66000387-C
Air chillers and heat pumps MPI DC
Rated technical data of water chillers
Rated technical data of heat pumps
(1) Water temperature 12/7 °C, outdoor air temperature 35 °C (UNI EN 14511:2011)
(2) Water temperature 40/45 °C, outdoor air temperature 7 °C D.B. / 6 °C W.B. (UNI EN 14511:2011)
(3) Sound power level measured according to UNI EN ISO 9614
(E) EUROVENT certied data
MPI DC - C 010 M 014 018 023 029
Power supply V-ph-Hz 230-1-50 400-3N-50
Cooling capacity (1) (E) kW 10,5 14,2 18,0 22,8 28,9
Power input (1) (E) kW 3,42 4,89 7,82 7,91 12,5
EER (1) (E) 3,07 2,90 2,31 2,88 2,31
ESEER (E) 4,17 4,09 4,03 3,87 3,98
Eurovent eciency class B B E C E
Water ow (1) l/h 1819 2455 3127 3935 4997
Water pressure drop (1) (E) kPa 23 30 47 27 42
Available pressure head - standard pump (1) kPa 142 162 132 130 84
Maximum current absorption A 27 20 22 29 43
No. of compressors / circuits n° 1/1 1/1 1/1 1/1 1/1
Expansion vessel dm
3
5 5 5 5 5
Buer tank volume dm
3
30 30 30 50 50
Sound power level (3) (E) dB(A) 70 71 71 74 74
Transport weight unit with pump and tank kg 184 218 218 262 262
Operating weight unit with pump and full tank kg 201 235 235 299 299
MPI DC - H 008 M 010 M 014 018 023 029
Power supply V-ph-Hz 230-1-50 230-1-50 400-3N-50
Cooling capacity (1) (E) kW 7,94 10,3 13,9 17,7 22,3 28,3
Power input (1) (E) kW 2,65 3,42 4,89 7,81 7,90 12,5
EER (1) (E) 3,00 3,02 2,85 2,26 2,83 2,27
ESEER (E) 3,81 4,09 4,06 3,96 3,78 3,91
Eurovent eciency class B B C F C F
Water ow (1) l/h 1367 1785 2407 3067 3861 4903
Water pressure drop (1) (E) kPa 6 22 29 44 26 40
Available pressure head - standard pump (1) kPa 68 142 163 133 131 84
Heating capacity (2) (E) kW 8,95 11,5 15,8 21,8 24,7 34,0
Power input (2) (E) kW 2,84 3,64 5,08 7,70 8,02 12,0
COP (2) (E) 3,15 3,16 3,11 2,83 3,09 2,83
Eurovent eciency class B A B C B C
Water ow (2) l/h 1550 1986 2727 3752 4273 5853
Water pressure drop (2) (E) kPa 7 23 31 55 29 51
Available pressure head - standard pump (2) kPa 65 137 155 109 116 45
Maximum current absorption A 16 27 20 22 29 43
No. of compressors / circuits n° 1/1 1/1 1/1 1/1 1/1 1/1
Expansion vessel dm
3
1 5 5 5 5 5
Buer tank volume dm
3
20 30 30 30 50 50
Sound power level (3) (E) dB(A) 68 70 71 71 74 74
Transport weight unit with pump and tank kg 144 188 243 243 290 290
Operating weight unit with pump and full tank kg 153 205 260 260 327 327
