BenQ PN Description
5J.JCY10.001 Ceiling mount (CM00G4)
98.0 (3.85)
547.8 (21.56)
372.8 (14.67)
y
Desktop Installation
C
H
0.05H
Shift Range
Screen Center
Note:
• The drawings apply to the standard lens only.
• Lens Shift feature is not available to LS2ST3 (Fix Lens). This lens should be used for "zero degree"/"no-offset"
applications. See below:
C
113.5
Screen Center
FOR USE WITH LS2ST3 (FIX LENS) ONLY
