4 Installation
4.1 Installation clearance requirements
Thehydraulicconnectionsareallforeseenontherightsideoftheunit,whenlookingatthefrontpanel.Thiswaythe
backoftheunitcanbeagainstthewall.Itisessentialtoensurethefollowingservicespaces:
‐ rearside
:min.0m
‐ electricpanelside
:atleast1mtoguaranteeaccessforinspectionsand/orformaintenanceofcoolingcomponents
‐ rightside
:1mtobeabletoconnectthehydraulicpipingproperly
‐ topside
:min.1m
‐ leftside
:0.5m
ThesedistancesrefertostandardversionsofLEWunits;thesameconsiderationsapplytotheoptionalhydronic
modules.
When installing the unit, for safety purposes, make sure that the room temperature does not
exceed 50°C (with unit on or off).
4.2 Volume of water in the system
TheON/OFF‐typecompressorsworkintermittently,sincethecoolingpowerrequiredbytheutilityisnotgenerallythe
sameasthatsuppliedbythecompressor.Insystemscontaininglittlewater,inwhichthethermalinertiaislow,verify
thatthewatercontentofthedeliverysection(tousers)satisfiestheequationbelow:
NsSh
Cc
V
V = water content in user section [m3]
Sh = specific heat of fluid [J/(kg/°C)] e.g. 2090 [J/(kg/°C)] for water
= density of fluid [kg/m3] e.g. 1000 [kg/m3] for water
D = minimum time between 2 compressor restarts [s] e.g. 120 [s]
DT = admissible differential on water T [°C] e.g. 4 [°C]
Cc = Cooling Capacity [W]
Ns = N° of capacity control steps
