Page55of56

RG66006951‐Rev.01



Attention: do not modify the calibration of the maximum pressure switch. Should the latter fail

to work, rising pressure causes the high pressure safety valve to open.

Thehighpressureswitchmustberesetmanually;thisispossibleonlywhenthepressuredropsbelowthevalue

indicatedbythesetdifferential(seeTableII).



Calibrationoftheminimumpressureswitch

Thelowpressureswitchstopsthecompressorwhentheintakepressurefallsbelowthesetvalueformo

rethan120

seconds.

Itisresetautomaticallyonlywhenthepressurerisesabovethevalueindicatedbythesetdifferential(seeTableII).



Calibrationoftheservicethermostatfunction

Thisfunctionstartsandstopsthecompressorsaccordingtothewatertemperaturereadingatthechillerunitinlet

[waterreturningfromthesystem].Refertothesectionofthedo

cumentonthemicroprocessorcontrolforfurther

details.



Calibrationoftheantifreezethermostatfunction

Theantifreezeprobeislocatedattheevaporatoroutletandstopsthecompressorifthewatertemperaturedrops

belowthepresetlimit.Togetherwiththeflowswitchan

dlowpressureswitch,thisdeviceprotectstheevaporatorfrom

theriskoffreezingasaresultoffaultsinthewatercircuit.Refertothemicroprocessorcontrolmanualforfurther

details



Calibrationoftheanti‐recycletimerfunction

Thetimerfunctionpreventsexcessivelyfrequentcompressorstartsandstops.Itimposesaminimumti

melapseof480

secondsbetweentwosuccessivestarts.Refertothemicroprocessorcontrolmanualforfurtherdetails.

Never change the delay time set by the manufacturer: incorrect values could cause serious

damage to the unit.


