galletti.com VM66000387-01
Production of chilled water
with total condensation heat
recovery for DHW production
Energy saving thanks to a total recovery
Galletti multi-purpose heat pumps are total recovery units used for a
simultaneous hot and cold water production. Available for a 2-pipe system,
DHW production under request, or a 4-pipe system, designed for service and
residential sectors.
As well as winter heating and summer air conditioning, in case of a 2-pipe
air-conditioning systems in which, thermal power for the DHW production
is required, Galletti multi-purpose systems are equipped with a plate heat
exchanger used for the DHW production.
Thanks to the advanced technology of these systems, they can satisfy this request
in every season, also when there is no need of air-conditioning, but that’s not
all! They can do that efficiently by using the total recovery of condensation heat
available during cooling phase.
S3
S2S1
LEGEND:
S1: “user side” plate exchanger
S2: “DHW production side” plate exchanger
S3: Finned block heat exchanger
DOMESTIC HOT WATER
HEAT PUMPCOOLING
Boiler
Boiler
Domestic
hot water
Water
system
Radiant
system
Fan coil
p
h
Heating/DHW
Cooling
TOTAL HEAT RECOVERY
MULTIPURPOSE HEAT PUMPS
