CHV190 series special inverter for crane
- 205 -
Function
Code
Name Description
Setting
Range
Factory
Setting
Modify
P5.14
ON-OFF filter
times
1~10 1~10 5 ○
P5.15 AI1 lower limit
0.00V~10.00V 0.00~10.00
0.00V
○
P5.16
AI1 lower limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
0.0% ○
P5.17 AI1 upper limit
0.00V~10.00V 0.00V~10.00
10.00V
○
P5.18
AI1 upper limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
100.0%
○
P5.19
AI1 filter time
constant
0.00s~10.00s 0.00~10.00
0.10s ○
P5.20 AI2 lower limit
0.00V~10.00V 0.00~10.00
0.00V
○
P5.21
AI2 lower limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
0.0% ○
P5.22 AI2 upper limit
0.00V~10.00V 0.00~10.00
5.00V
○
P5.23
AI2 upper limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
100.0%
○
P5.24
AI2 filter time
constant
0.00s~10.00s 0.00~10.00
0.10s ○
P5.25 HDI1 lower limit
0Hz~50.0kHz 0~50.0 0.0kHz
○
P5.26
HDI1 lower limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
0.0% ○
P5.27 HDI1 upper limit
0Hz~50.0kHz 0~50.0 50.0kHz
○
P5.28
HDI1 upper limit
corresponding
setting
-100.0%~100.0% -100.0~100.0
100.0%
○
P5.29
HDI1 filter time
constant
0.00s~10.00s 0.00~10.00
0.10s ○
P5.30 Reserved 0~65535 0~65535 0 ◎
