CHV190 series special inverter for crane
- 206 -
Function
Code
Name Description
Setting
Range
Factory
Setting
Modify
P5.31 Reserved 0~65535 0~65535 0 ◎
P5.32 Reserved 0~65535 0~65535 0 ◎
P5.33 Reserved 0~65535 0~65535 0 ◎
P5.34 Reserved 0~65535 0~65535 0 ◎
P5.35 Reserved 0~65535 0~65535 0 ◎
P6 Group: Output terminals
P6.00 HDO selection
0: High-
speed pulse
output
1: ON-OFF output
0~1 0 ◎
P6.01
Y1 output
selection
0~20 1 ○
P6.02
Y2 output
selection
0~20 0 ○
P6.03
HDO ON-OFF
output selection
0~20 0 ○
P6.04
Relay 1 output
selection
0~20 4 ○
P6.05
Relay 2 output
selection
0~20 5 ○
P6.06
Relay 3 output
selection
0: No output
1: Motor running
2: Up running (UR)
3: Down running (DR)
4: Fault output
5: Zero speed running
6: Ready
7: Brake control
8: Contactor control
9: Frequency reached
10: FDT reached
11: Motor running1 (LR1)
12: Closing output (FO)
13: Motor switching
output
14: Motor excitation
15: Motor excitation
completion output
16: Sling loose alarm
output
17: High-
speed signal
output
18: Motor over
temperature alarm
0~20 0 ○
