CHV190 series special inverter for crane
- 124 -
● Ambient temperature: 0 ℃ ~ +40 ℃
● Relative humidity: 5% ~ 95%
● Other climate conditions: non-condensing, freezing, rain, snow, hail, etc., solar
radiation below 700W/m
2
, air pressure 70~106kPa
● Salt spray and corrosive gases: Pollution Level 2
● Dust and solid particles content: Pollution Level 2
● Vibration and shock: 5.9m/s2 (0.6g) when sinusoidal vibration is 9~ 200Hz.
Installation steps:
● Fix three copper columns to H5, H6 and H7 on the panel.
● Insert module into socket J20 on the control board carefully, then fixed to the
connecting column.
● Set bus termination switch of module to the desired location.
Notice:
Be sure that power is cut off and wait at least 3 minutes to ensure the completion of
capacitor discharge. Cut off dangerous voltages which is external control circuit to
unit input and output terminals.
Electronic components on the CH-PA01 adapter module circuit board are sensitive
to electrostatic discharge. Do not touch circuit boards with hands. Please wear a
grounded wrist strap when you need dealing with circuit boards.
7.5.2.2 Adapter electrical Installation
7.5.2.2.1 Node selection
Node address is the only address that devices have on the Profibus bus, and it is decided
by rotative switch of node address selection. The range of node address number is from
00~99. The left switch represents first number and the right switch represents second
number.
Node Address = 10*first number + 1*second number
Figure 7.20 Node selection
7.5.2.2.2 Bus terminators
Each head and tail has a bus terminator to ensure that error doesn’t occur in the operation.
DIP switches on CH-PA01 are connected to the bus terminator which can prevent signal
reflection. If the module is the first or the last one in the network, the bus terminator must
