CHV190 series special inverter for crane
- 160 -
LRC CHK Hi
‘5’
LRC CHK Lo
‘9’
END Lo
CR
END Hi
LF
10.7.5 RTU mode, diagnose that the asked data bytes of address 01H should be the
same as responds.
The request command is:
START T1-T2-T3-T4
Node address 01H
Command 08H
High byte of data address 00H
Low byte of data address 00H
High byte of write content 12H
Low byte of write content ABH
Low byte of CRC ADH
High byte of CRC 14EH
END T1-T2-T3-T4 (transmission time of 3.5 bytes)
The reply command is:
START T1-T2-T3-T4 (transmission time of 3.5 bytes)
Node address 01H
Command 08H
High byte of data address 00H
Low byte of data address 00H
High byte of write content 12H
Low byte of write content ABH
Low byte of CRC ADH
High byte of CRC 14H
END T1-T2-T3-T4 (transmission time of 3.5 bytes)
10.7.6 ASCII mode, diagnose that the asked data bytes of address 01H should be
the same as responds.
The request command is:
START
‘:’
‘0’
Node address
‘1’
