7. Parameters
7.1. Standard parameters
Par. Description Range Default Explanation
P-01 Maximum speed P-02 to 5*P-09 (max 500Hz)
50Hz
(60Hz)
Maximum speed limit – Hz or rpm. See P-10
P-02 Minimum speed 0 to P-01 (max 500Hz) 0Hz Minimum speed limit – Hz or rpm. See P-10
P-03
Acceleration ramp
time
0 to 600s 5s
Acceleration ramp time from 0 to base speed
(P-09) in seconds
P-04
Deceleration ramp
time
0 to 600s 5s
Deceleration ramp time from base speed (P-09)
to standstill in seconds.
When P-04=0, the deceleration ramp is set by
P-24. Setting P-04=0 also activates dynamic
ramp control, where the ramp may be extended
automatically to prevent an O-Volt trip.
P-05 Stop mode select
0 : Ramp stop
(brown-out ride-through)
1 : Coast to stop
2 : Ramp to stop (fast stop)
0
If the supply is lost and P-05=0 then the drive
will try to continue running by reducing the
speed of the load using the load as a generator.
If P-05 = 2, the drive will ramp to stop using the
P-24 decel ramp with dynamic brake control
when mains supply lost.
P-06 Energy Optimiser
0: Disabled
1: Enabled
0
When enabled, automatically reduces applied
motor voltage on light load. Minimum value is
50% of nominal.
P-07 Motor rated voltage
0, 20V to 250V
0, 20V to 500V
230V
400V
(460V)
Rated (nameplate) voltage of the motor (Volts).
Value limited to 250V for low voltage drives.
Setting to zero disables voltage compensation
P-08 Motor rated current
25% -100% of drive rated
current
Drive
rating
Rated (nameplate) current of the motor (Amps).
P-09
Motor rated
frequency
25Hz to 500Hz
50Hz
(60Hz)
Rated (nameplate) frequency of the motor.
P-10 Motor rated speed 0 to 30 000 rpm 0
When non-zero, all speed related parameters
are displayed in rpm
P-11 Voltage boost
Size 1: 0.0 to 20.0%
Size 2: 0.0 to 15.0%
Size 3: 0.0 to 10.0%
of max output voltage.
Motor
power
dependent
Applies an adjustable boost to the Optidrive
voltage output at low speed to assist with
starting ‘sticky’ loads. For continuous
applications at low speed use a forced
ventilated motor.
P-12
Terminal / Keypad /
MODBUS / PI
Drive Control Mode
Selection
0.Terminal control
1. Keypad control – fwd only
2. Keypad control − fwd and
rev
3. MODBUS network control
with internal accel / decel
ramps
4. MODBUS network control
with accel / decel ramp
adjustment
5. User PI control
6. User PI control with analog
input 1 summation
0
Primary Control Mode of the drive.
0. Terminal control
1. Uni-directional keypad control. Keypad
START button does not reverse direction.
2. Bi-directional keypad control. Keypad START
button toggles between forward and reverse.
3. Control via Modbus RTU (RS485) comms
interface using the internal accel / decel ramps
4. Control via Modbus RTU (RS485) comms
interface with accel / decel ramps updated via
Modbus
5. User PI control with external feedback signal
6. User PI control with external feedback signal
and summation with analog input 1
P-13 Trip log Last four trips stored Read only
Previous 4 trips stored in order of occurrence,
with the most recent first.
Press UP or DOWN to step through all four.
The most recent trip is always displayed first.
UV trip is only stored once.
Further fault event logging functions are
available through parameter group zero.
P-14
Extended menu
access
Code 0 to 9 999 0
Set to “101” (default) for extended menu
access.
Change code in P-39 to prevent unauthorised
access to the Extended Parameter Set
NOTE Default parameter values for Horse Power rated drives are shown in brackets
NOTE Standby mode is enabled automatically when the drive is at zero speed for > 20 seconds
