KSB Etaline ETL-125-125-160 200L [21/90] Etaline etaline r

Etaline 50-50-160, n = 2900 rpm

K1159.452/26/0

0 20 40 60 80

Q [m³/h]

0 100 200 300 400

Q [US.gpm]

0 100 200 300

Q [IM.gpm]

H [m]

100

H [ft]

0 5 10 15 20 25

Q [l/s]

NPSH

[m]

NPSH

[ft]

P [kW]

P [hp]

0 20 40 60 80

Q [m³/h]

ø174

ø162

ø148

ø133

ø120

Qmin

71.0

70.8

70.7

67.7

62.7

η [%]

Heating / Air-conditioning / Ventilation

In-line Pumps

Etaline / Etaline-R
