System overview
1.4 System data
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
25
1.4 System data
Table 1- 1 General technical data
Electrical data
Line supply voltage:
Blocksize format units
1-ph. 200 V to 240 V AC ±10 %
3-ph. 380 V to 480 V AC ±10 %
Rated pulse frequency:
Blocksize format units
4 kHz
Line frequency 47 Hz to 63 Hz
Output voltage:
Blocksize format units
0 V to rated line supply voltage at 3-ph. 380 V up to 480 V AC units,
0 V to 0.78 of the line supply voltage for 1-ph. 200 V to 240 V AC units.
Electronics power supply 24 V DC -15/+20 %*
)
, safety extra-low voltage DVC A (PELV)
Short-circuit current rating SCCR in accordance
with UL508C (up to 600 V)
1.1 kW – 447 kW: 65 kA
448 kW – 671 kW: 84 kA
672 kW – 1193 kW: 170 kA
≥ 1194 kW: 200 kA
Radio interference suppression
acc. to EN 61800-3
Category C3 (option)
Category C2 (option)
for systems implemented in conformance with the documentation
Overvoltage category III acc. to EN 60664-1
Degree of pollution 2 acc. to 60664-1
*) If a motor holding brake is used, restricted voltage tolerances (±10%) may have to be taken into account.
Environmental conditions
Degree of protection IP20 or IPXXB acc. to EN 60529, open type acc. to UL 508
Protective class line supply circuits
Protective class electronic circuits
I (with protective conductor connection)
III (safety extra-low voltage DVC A /PELV) acc. to EN 61800-5-1
Type of cooling Internal air cooling,
power units with forced air cooling using an integrated fan
Permissible cooling medium temperature (air)
and installation altitude in operation
0 °C to +40 °C and an installation altitude of up to 1,000 m without
derating, >40 °C to 55 °C, see the characteristic for current derating.
Installation altitude >1,000 m and up to 4,000 m, see the characteristic
for current derating or reduction of the ambient temperature by 3.5 K
per 500 m.
Chemically active substances
Long-term storage in the transport packaging
Transport in the transport packaging
Operation
Class 1C2 to EN 60721-3-1
Class 2C2 to EN 60721-3-2
Class 3C2 to EN 60721-3-3
