High Performance Vector Control/Torque Control Inverter User Manual
160
Appendix D PG Card Lectotype and Connection Diagram
Encoder
Vcc
0V
A+
A-
+5V
PA-
GND
PA+
PE
EX-PG04
Inverter
OUTA+
OUTA-
OUTB+
A+ phase frequency
division output
A- phase frequency
division output
Shielded wire
B+
B-
PB+
PB-
OUTB-
B+ phase frequency
division output
B- phase frequency
division output
Z+ PZ+
Z- PZ-
OUTZ+
Z+ phase frequency
division output
OUTZ-
Z- phase frequency
division output
Connection diagram for EX-PG04 card adopting internal power supply
Encoder
Vcc
0V
A+
A-
+5V
PA-
GND
PA+
PE
EX-PG04
Inverter
OUTA+
OUTA-
OUTB+
A+ phase frequency
division output
A- phase frequency
division output
Shielded wire
B+
B-
PB+
PB-
OUTB-
B+ phase frequency
division output
B- phase frequency
division output
Z+ PZ+
Z- PZ-
OUTZ+
Z+ phase frequency
division output
OUTZ-
Z- phase frequency
division output
External power
External power ground
Connection diagram for EX-PG04 card adopting external power supply
