![KSB Multitec MTC A 100/8C [29/34] High pressure pumps](/views2/1592699/page29/bg1d.png)
Dimensions of Multitec V
Connections
Connection G = ISO 228/1,
Rp = ISO 7/1
Multitec V
32 50 65 100 125 150
1M.1 G ½ ½ ½ ½ ½ ½
1M.2 G ½ ½ ½ ½ ½ ½
6B.3 G ¼ ¼ ½ ½ ½ 1
8B Rp ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
Shaft dimensions [mm]
Size d
7
t
3
u
1
Size d
7
t
3
u
1
32 30 33 8 100 40 43 12
50 30 33 8 125 50 53,5 14
65 35 38 10 150 60 64 18
Dimensions of Multitec V [mm]
Multitec V
Number of stages
DN
1
DN
2
b
11
d
4
e g h
2
h
4
m
5
m
6
s t
1
32 2 50 32 490 18 121 M16x250 MU 175 129 345 266 20 250
3 50 32 490 18 176 M16x250 MU 175 129 345 266 20 250
4 50 32 490 18 231 M16x250 MU 175 129 345 266 20 250
5 50 32 490 18 286 M16x250 MU 175 129 345 266 20 250
6 50 32 490 18 341 M16x250 MU 175 129 345 266 20 250
High-pressure Pumps
High-pressure Centrifugal Pump
Multitec/Multitec-RO
29
