User Manual
Chapter 2. Commands for 802.1x 48
www.qtech.ru
Authentication Method:
Port authentication method (MAC-based, port-
based, user-based)
Status
Port authentication status
Port-control
Port authorization status
Supplicant
Authenticator MAC address
Authenticator State
Machine
Authenticator state machine status
Backend State Machine
Backend state machine status
Reauthentication State
Machine
Re-authentication state machine status
2.34 user-control limit ipv4
Command: user-control limit ipv4 <count>
Function: Set the global max number of IPv4 controlled/trusted users.
Command Mode: Global Configuration Mode.
Default Settings: The max IPv4 user number supported by the switch is 128.
Usage Guide: This command is for setting the max IPv4 user number supported by the
switch, ranging from 1 to 700. This number limit is the sum of dot1x user number and
the trusted user number added by ip dhcp snooping binding user-control.
Example: Set the max IPv4 user number globally.
Switch(config)#user-control limit ipv4 100
2.35 user-control limit ipv6
Command: user-control limit ipv6 <count>
Function: Set the global max number of IPv6 controlled/trusted users.
Command Mode: Global Configuration Mode.
Default Settings: The max IPv6 user number supported by the switch is 256.
Usage Guide: This command is for setting the max IPv6 user number supported by the
switch, ranging from 1 to 1400. This number limit is the sum of the trusted user number
added by ipv6 dhcp snooping binding user-control and ipv6 nd snooping user-control.
