2 3
Instruction manual Instruction manual
terminal inside the battery compartment. This
is additional power intended for operation
of clock, alarm, termometer and countdown
timer. Without the additional power the unit will
function only as radio receiver.
General operations
Clock and calendar
• In clock mode (no ALARM indication)
press ADJ button to select 12-hour or 24-hour
clock display mode.
• Press repeatedly SET button to go to
setting of parameters in following sequence:
hour => minute => year => month => date.
The selected parameter will blink meaning
readiness for adjustment.
• Press ADJ button to adjust the parameter
up. Press C/F button to adjust the parameter
down.
• Day of week will be set automatically.
Termometer
The unit is equipped with a built-in
termometer. The current temperature is
updated every minute and is shown on the
display. In clock mode press C/F button to
select Celsium or Fahrenheit termometer mode.
AUX input
To connect an external audio device (eg.
MP3-player), please use a standard stereo
cable with 3.5 mm to 3.5 mm plugs to connect
the audio line-out of the external device to the
AUX input socket of this unit. Slide AUTO/OFF/
ON switch to ON position.
Radio operation
• Radio reception is only available when AA/
UM3 battery power or AC adaptor power is used.
• Slide AUTO/OFF/ON switch to ON. Select
AM or FM band with the FM/AM switch.
• For FM reception extend the telescopic
Important safeguards
• The instruction manual contains important
operating and maintenance instructions. For
your safety, it is necessary to refer the manual.
Keep the manual for use in future.
• Do not hit or drop the unit.
• Do not expose the unit to vibration, direct
sunlight, too high or low temperature or humidity.
• Do not use the unit near TV sets,
computers, fluorescent lamps and other
electric equipment; this may jam AM reception.
• Do not disassemble the unit yourself.
Refer servicing to qualified service personnel.
• When the battery is exhausted, it should
be removed from the set to prevent leakage.
Power supply
Battery power
• Open the battery compartment cover.
Insert 5 UM3 (1.5V) batteries. Please observe
correct battery polarities or the unit will not
work. Close the battery compartment cover.
• When the batteries are exhausted, they
should be replaced.
• Do not use new and old batteries together.
• Disconnect power cord from the socket,
when the unit is on battery supply. Battery
power is automatically disconnected when the
power cord is connected to a power socket.
AC adaptor power
• Plug the supplied AC/DC power adaptor into
the power input on the back of the unit. Connect
the power cord to the AC household main outlet.
Make sure the voltage is compatible.
• Always remember to disconnect the
power cord from the main supply before
disconnecting it from the unit.
• Disconnect the power cord from the mains
when not in use.
Additional power
There are 2 batteries AG3 (1.5 V) in the
