LINE
Technical Data
Installation MaintenanceWiring
Installation
INSTALLATION INSTRUCTIONS -
NOTICE D'INSTALLATION
NOTICIA DE INSTALACIÓN - INSTALLATIONSHINWEISE
ISTRUZIONI PER L'INSTALLAZIONE
INSTRUCOES DE INSTALACAO - MONTÁŽNÍ NÁVOD
РУКОВОДСТВО ПО МОНТАЖУ - 安装指导书
Dataline surge protector -
Parafoudre pour ligne de données
Proteccion para lineas datos
Überspannungsschutz für Datentechnik
Protezione per linee dati
Protetor de Surto para linha de dados.
DLA-xx-IS Series
DLA
DLA-12-IS
DLA-06-IS
Uc
8 Vdc / 6 Vac
15 Vdc / 10 Vdc
P/N
6500 ft max.
2000 m ma
x.
-40/+185°F max.
-40/+85°C max.
IP20
indoor use only
IN
EQUIP
t
OUT
PE
example
EQUIP
t
Surge
Protection
Device
Clip on
symmetrical
DIN rail
1
0.4 in
10mm
0.4-2.5 mm²
#21-13 AWG
2
DLA
3
4
#13 AWG max
2.5 mm² max
5
0.5 Nm
4.4 LB-IN
LINE
to EQUIP
t
Data-Pair
DIN rail
135
7911
81012
246
DLA-xx-IS
1:
IN = Data-Pair
5:
2:
OUT = Data-Pair
6:
IN 3:
= indirect grounding of the shield via Gastube
OUT 4:
IN 7:
= Signal Ground (if avialble)
OUT 8:
IN 11:
= direct grounding of the shield
OUT 12:
9 or 10 or DIN RAIL: = Equipotential System
Data-Pair
Cable shield
4 or 12 *
Cable shield
to 3 or 11
Signal ground
(if available)
Signal ground
(if available)
* please chose 3-4 or 11-12 depending
if the application allowes a direct grounding of the shield (11-12) or a indirect grounding via gastube is necessary (3-4)
DLA
and replace
with
DLAM-xx-IS
X
DLA
X
X
External
