Technical Data
Wiring :
SPD mounting on a 40mm busbar system
Dimensions (in mm)
Maintenance
INSTALLATION INSTRUCTIONS -
NOTICE D'INSTALLATION
NOTICIA DE INSTALACIÓN - INSTALLATIONSHINWEISE
ISTRUZIONI PER L'INSTALLAZIONE
INSTRUCOES DE INSTALACAO - MONTÁŽNÍ NÁVOD
РУКОВОДСТВО ПО МОНТАЖУ - 安装指导书
AC surge protector for 40 mm busbar systems -
AC- Blitzstromableiter für 40mm Sammelschienensystem
Table 2
TT SystemTN-S System
N180801c
230/400 Vac 3L+N
ZPAC1-8VG-31-275
ZPAC1-13VG-31-275
P/N
I
PE
I
max*
I
SCCR
I
imp*
50 kA
1 - port SPD
50 kA
8 kA 12.5 kA
6500 ft max.
2000 m ma
x.
-40/+185°F max.
-40/+85°C max.
IP20
(built in)
indoor use only
Humidity range
5% - 95%
Port conguration
None
Characteristics
AC network
AC System
TN-S
TT
16 mm
0.6 in
VDE-AR-N 4100 conform
* Value per pole
Installation
ZPAC1 Series
Not GREEN = DEFECTIVE
X
GREEN indicator = OK
DEFECTIVE
Replace with
MDAC1-xxVG-275
plug-in module
X
10 - 50 mm²
10 - 35 mm²
Min-Max for PE
3
1
Insert on
the first busbar
system
Push on
the last
busbar system
Choose position for
a 5 mm thick busbar
6
4
5
7
3.5 - 4 Nm
31 - 35.4 Lb-In
Note: remove the protection
film if needed
Cross recess
PZ-2
X
There is no minimum distance required from the SPD to any earthed conductive surface.
Put the clip bracket
on this position
Or
57
95
53.8
18.3
211
L1
L2
L3
N
PE
N
L3
L2
L1
kWh
PE
F1 ≤ 160A gL/gG
ZPAC1-8VG-31-275
ZPAC1-13VG-31-275
L1
L2
L3
N
N
L3
L2
L1
kWh
PE
F1 ≤ 160A gL/gG
ZPAC1-8VG-31-275
ZPAC1-13VG-31-275
Position for
a 10 mm thick busbar
2
Push the clip
to fix ZPAC
