CITEL DAC40C-40-150 Инструкция по установке онлайн

CITEL DAC40C-20-150 Инструкция по установке онлайн
Installation Maintenance
Wiring
5
1.2 - 1.5 Nm
10.6 - 13.3 Lb-In
1
2
4
INSTALLATION INSTRUCTIONS -
NOTICE D'INSTALLATION
NOTICIA DE INSTALACIÓN - INSTALLATIONSHINWEISE
ISTRUZIONI PER L'INSTALLAZIONE
INSTRUCOES DE INSTALACAO - MONTÁŽNÍ NÁVOD
РУКОВОДСТВО ПО МОНТАЖУ - 安装指导书
AC surge protector -
Parafoudre Basse Tension
Protectiones Baja Tension
Überspannungsschutz für Niederspannungsnetze
Scaricatori da sovratensioni per rete di energia
Protetor de Surto CA. - Svodiče přepětí pro AC
Устройство защиты от импульсных
перенапряжений, AC - 低压浪涌保护器
DAC40C series
1.5 - 16 mm
2
15 - 5 AWG
1.5
- 10 mm
2
15 - 7 AWG
min-max (L1-L2-L3-N)
2.5 - 35 mm
2
13 - 2 AWG
2.5
- 25 mm
2
13 - 4 AWG
min-max (PE)
16 mm
0.63 in
Clip on
symmetrical
DIN rail
11-12 Closed = SPD OK
11-14 Open = SPD OK
Remote signal for
disconnection information
11-12 Open = SPD disconnect
11-14 Closed = SPD disconnect
Remote contact wiring
*** depending on national rules : Solution or Table 2 Table 3
F1 ≤ 125 A
F1 > 125 A
F2
No F2
=
125 A
Standard wiring
Fuses Type gG
GREEN indicator
3
2.0 - 2.5 Nm
17.8 - 22.1 Lb-In
N181101b
Remote signal for
disconnection information
Remote contact wiring
Table 3
1,5 mm²
# 14 AWG max
2.1 Lb-In
0,5 Nm max.
250 Vac / 0.5 A max.
30 Vdc / 3 A max.
OK
DEFECT
Replace with
MDAC40C-xxx
1 2
F2 ≤ F1
1 2
*** ***
12
11
14
Cross recess
PZ-2
** Note: take off the protection film if needed
6 mm² min.
a
b
c
F2
F1
∑
a+b+c
≤ 50 cm
≤ 20 inch
SPD
X
NOT Green indicator
DAC40CS
12
11
14
L
N
F2
PE
F1
L2
L1
L3
N
F2
PE
F1
L2
L1
L3
N
F2
PE
F1
Technical Data
6500 ft max.
2000 m ma
x.
-40/+185°F max.
-40/+85°C max.
IP20 (built in)
indoor use only
Humidity range
5% to 95%
Number of ports : 1
* Type of LV-System + regulation (e.g 10 %)
-
+
Table 1
Remote signal option: S: e.g DAC40CS-11-275
120/208 V
120/208 V
120/208 V
120/208 V
230/400 V
230/400 V
230/400 V
230/400 V
230/400 V
230/400 V
230/400 V
277/480 V
277/480 V
277/480 V
277/480 V
347/600 V
347/600 V
347/600 V
347/600 V
400/690 V
400/690 V
400/690 V
400/690 V
Ipe (per pole)
I
sccr (per pole)
I
max (per pole)
I
AC network *
AC system
Wiring
DAC40C(S)-20-150
DAC40C(S)-40-150
DAC40C(S)-11-150
DAC40C(S)-31-150
DAC40C(S)-20-275
DAC40C(S)-40-275
DAC40C(S)-11-275
DAC40C(S)-31-275
DAC40C(S)-20-320
DAC40C(S)-40-320
DAC40C(S)-11-320
DAC40C(S)-31-320
DAC40C(S)-20-440
DAC40C(S)-40
-440
< 1 mA / (or 0 mA for "11" a nd "31" versions)
10 kA
40 kA
NA
L+N
TN-S/TT
TN-S/TT
TN-S/TT
TN-S/TT
TN-S
TN-S
TN-S
TN-S
TN-S
TN-S
IT
IT
IT
TN-C
TN-C
TN-C
TN-C
TN-C
TN-C
TN-C
TN-C
TN-C
TN-C
L+N
3L
3L
3L
3L
3L
3L
3L+N
3L+N
3L+N
3L+N
3L+N
3L+N
L+N
L+N
L+N
L+N
L+N
L+N
L+N
L+N
L+N
L/PE
L/PE L/PE
L/PE
L/PE
X
Dimensions (mm)
18
36
Note: take off the protection film
if needed (see below)
Application example
L2
L1
L3
N
PE
Main switchboard
or sub-panel
F1
F2
**
73.5
90
8.8
44
67
Fuses to use :
50 A min. - 125 A max.
