Installation Maintenance
Application example
LSC-A Series
Display ON
Display OFF
The display indicates the
number of lightning
strikes or surges
Technical Data
Torward bonding
network (PE)
AC line
IN
AC line
OUT
The grounding wire must pass
below the lightning counter
Mounting and earthing over DIN railMounting and earthing over at or round grounding wire Operating
AC Network
6500 ft max.
2000 m ma
x.
-40/+185°F max.
-40/+85°C max.
LSC-A
LSC-A/DIN
Minimum current sensibility
Maximum numbers of events
Max. admissible impulse current
Type of display
P/N
0.5 kA
100 kA
999999
LCD
IP67
Characteristics
INSTALLATION INSTRUCTIONS - NOTICE D'INSTALLATION
NOTICIA DE INSTALACIÓN - INSTALLATIONSHINWEISE
ISTRUZIONI PER L'INSTALLAZIONE
INSTRUCOES DE INSTALACAO - MONTÁŽNÍ NÁVOD
РУКОВОДСТВО ПО МОНТАЖУ - 安装指导书
Lightning current counter -
Compteur de coups de foudre
Contador de rayos
Blitzstromzähler
Fulmini contro corrente - Contatore di colpi di fulmine.
Contadon de descangas
discharge
current
recorded
n
=
n+1
N160902
SPD monitoring:
LPS monitoring:
SPD
LPS
5
n
5
Degree of protection (IP)
Mounting over round or at conductor
Mounting over DIN rail
Indoor / Outdoor mounting
cable Clamp
Use flat grounding wire (30mm x 2mm)
or round groundind wire
(Ø 10mm to 16mm)
Clip on
symmetrical
DIN rail
OK
X
DEFECT
Return to
CITEL
