87
SHOE4 SERIESSHOE4 SERIES
SHOE4 SERIESSHOE4 SERIES
SHOE4 SERIES
DIMENSIONS AND WEIGHTS ADIMENSIONS AND WEIGHTS A
DIMENSIONS AND WEIGHTS ADIMENSIONS AND WEIGHTS A
DIMENSIONS AND WEIGHTS A
T 50 Hz, 4 POLEST 50 Hz, 4 POLES
T 50 Hz, 4 POLEST 50 Hz, 4 POLES
T 50 Hz, 4 POLES
DIMENSIONI E PESI SERIE SHOE4 4 poli 50 Hz
PUMP TYPE WEIGHT
BHLk
DNM DNA ah2 xh1 n max kg
SHOE4 25-125/03 25 50 80 140 121 112 190 219 252 421 98 19
SHOE4 25-160/03 25 50 80 160 121 132 210 254 292 421 98 23
SHOE4 25-160/05 25 50 80 160 129 132 210 254 292 453 98 25
SHOE4 25-160/07/C 25 50 80 160 128 132 210 254 292 421 98 27
SHOE4 25-200/07/C 25 50 80 180 128 160 230 284 340 421 98 30
SHOE4 32-125/03 32 50 80 140 121 112 190 219 252 421 98 19
SHOE4 32-160/03 32 50 80 160 121 132 210 254 292 421 98 23
SHOE4 32-160/05 32 50 80 160 129 132 210 254 292 453 98 25
SHOE4 32-160/07/C 32 50 80 160 128 132 210 354 292 421 98 27
SHOE4 32-200/07/C 32 50 80 180 128 160 230 284 340 421 98 30
SHOE4 40-125/03 40 65 80 140 121 112 190 219 252 431 100 21
SHOE4 40-160/05 40 65 80 160 129 132 210 254 292 463 100 26
SHOE4 40-160/07/C 40 65 80 160 128 132 210 254 292 431 100 27
SHOE4 40-160/11/P 40 65 80 160 134 132 210 254 292 498 100 31
SHOE4 50-125/07/C 50 65 100 160 128 132 210 254 292 451 104 28
SHOE4 50-125/11/P 50 65 100 160 134 132 210 254 292 518 104 34
SHOE4 50-160/11/P 50 65 100 180 134 160 210 254 340 518 104 35
SHOE4 50-160/15/P 50 65 100 180 134 160 210 254 340 518 104 38
shoe4-4p50-en_d_td
PUMP
DIMENSIONS (mm)
