Operating the telescope

Unthread the thumbscrews on the focuser tube.

Insert the diagonal mirror into the focuser tube and secure it by retightening the thumbscrews.

Unthread the thumbscrews on the diagonal mirror.

Insert the desired eyepiece into the diagonal mirror and secure it by retightening the

thumbscrews.

Finderscope assembly

Optical Finderscope

Red Dot Finderscope

Using the red dot finder

The red dot finder is a zero magnification pointing tool that uses a coated glass window to

superimpose the image of a small red dot onto the night sky. The red dot finder is equipped with a

variable brightness control, azimuth adjustment knob, and altitude adjustment knob. The finder is

simply look through the sight tube and move your telescope until the red dot overlaps the object.

Make sure to keep both eyes open when sighting.

Eyepiece assembly

Optical finderscopes are very useful accessories. When they are correctly aligned with the

telescope, objects can be quickly located and brought to the center of the view. Alignment is best

done outdoors in day light when it's easier to locate objects. If it is necessary to refocus your

finderscope, sight it on an object that is at least 500 yards away. For 5x24 and 6x24 finderscopes:

turn the scope end to adjust the focus. For 6x30 finderscopes: loosen the locking ring by

unscrewing it back toward the bracket. The front lens holder can now be turned in and out to

focus. When focus is reached, lock it in position with the locking ring.

Choose a distant object that is at least 500 yards away and point the telescope at the object.

Adjust the telescope so that the object is in the center of the view in your eyepiece. Check the

finderscope to see if the object is also centered on the crosshairs.

For 5x24 and 6x24 finderscopes: use three adjustment screws to center the finderscope crosshairs

on the object. For 6x30 finderscopes: adjust two windage screws only.

Remove two locking nuts from protruding bolts on the optical tube (close to the focuser).

Attach the finderscope bracket to these bolts on the optical tube and lock it in place with

thumbscrews.

Insert the finderscope bracket into a holder on the telescope tube and lock it in place with a

thumbscrew.

Aligning the finderscope
