Telefunken TF-PS1228B [5/16] Accessories

Instruction Manual

Maintenance and care

Switch off the unit, unplug from the power

supply. The outside of the appliance can be

cleaned with a slightly damp cloth.

Accessories

1 pc

Audio system

Charging cable

Instruction manual

1 pc

Specifications

Specifications and functions are subject to change without notice. It is connected with continual

improvement of the device.

MANUFACTURED AND DISTRIBUTED BY TECHNO ELECTRIC LIMITED,

Legal address: 801 Luk Yu Building, 24 - 26 Stanley Street, Central, China

TELEFUNKEN and the TELEFUNKEN logo are trademarks of

TELEFUNKEN Licenses GmbH and are used under a trademark license.

Input voltage DC 5 V, 1 A

Nominal power consumption 5 W

FM radio 87.5 - 108 MHz

Battery power supply Li-ion, 3.7 V, 800 mA/h

Net weight 0.8 kg

Unit dimensions 150 x 100 x 230 mm

Output power 8 W

USB/TF operation

Playback

Turn on the device.

Insert a microSD (TF) card into the slot.

Or insert a USB drive into the USB

port. Press the M button repeatedly to

select the USB/TF mode.

• When playing, you can press

to play/pause the playback.

• During the playback you can press and

•

hold the and buttons to adjust the

volume and press them once to go to the

next and previous track.

It may take up to 60 seconds to open

and verify a large TF card / USB drive with

many files.

General USB/TF notes

• This unit is equipped with a TF slot

and USB port that can read and play MP3 files

stored on standard TF cards and USB drives up

to 32 GB.

• FAT and FAT32 file system is supported by

this unit.

Never remove TF cards and USB drives from

the unit during playback, always stop playback,

then press the M button to switch to another

mode before removing the storage to prevent

damage to your files and cards/drives

themselves.

FM radio

Turn on the device.

Press the M button repeatedly to

select the FM mode.

• Press to automatically scan and

save all available radio stations. The

procedure will take several minutes and

cannot be interrupted.

• Once the search is finished, you can

•

press the and buttons to go to a

previous or next radio station. Press and

hold these buttons to adjust volume.

• You can insert a microphone for karaoke

or other purposes into this unit by

connecting it to the 6.3mm microphone

input jack.

• While connected, you can control the

microphone volume with - and + buttons.

Microphone
