041 6192600 Burner bar type 352/11P L=282 m
042 6221612 Ignition electrode
044 6084600 Pilot burner fixing
044A 6221403 Ionisation electrode plate
045 6078000 Polidoro pilot burner type 470F
046 6066102 Pilot burner nozzle Ø 0,29 natu
046A 6066101 Pilot burner nozzle Ø 0,24 LPG
047 6221603 Ionisation probe
048 6089700 Honeywell gas valve V4600C 3/4"
048A 6243800 SIT 830 TANDEM gas valve 0.830.
049 6025701 Honeywell gas valve operator V4
050 6032400 Honeywell pressure governor V53
051 6168601 Nut for feeding pipe
052 6226402 OR gasket 21x6 XP70
052A 2030268 Piracriten gasket Ø 16X27,4X2,5
054 6239802 Gas inlet pipe for gas valve V4
054A 6184002 Gas inlet pipe for gas valve V4
056 6180011 Interrupted thermocouple
057 6073700 Piezo-igniter
058 6023000 Ignition electrode c/w lead L=3
059 6034202 Plastic pipe Ø 33x238
060 5058982 Casing right hand side panel
061 5059092 Casing left hand side panel
062 2003000 Pin M5 Zn
063 2015000 Spring clip
064 6085804 Rear panel
065 6173301 H.L. stat IMIT LS3 type 5.4176.
066 6063000 Limit stat securing bracket
067 6196102 Side panels lower bracket
068 6261000 Control panel
069 6173300 H.L. stat auto reset Ranco
070 6178830 Brahma FM11 control box
071 6003600 Boiler stat 45-85°C
072 6240102 Boiler stat handle Ø 35 mm
073 6013502 White switch with warning light
074 6146001 Thermometer 0-120°C
075 6001402 Smoke stat
076 6255300 H.L. stat plastic plug
077 2211000 Terminal strip
078 6146101 Hydrometer
079 6070410 Red pushing button
080 6266900 Anti-jamming filter
081 6261200 Plastic cover (white)
082 6261201 Control panel transparent flap
083 6261100 Control panel protection RX
084 6023300 Door lower right hinge
085 6023400 Door upper right hinge
086 5059411 Casing front upper door
091 6086192 Casing top cover
093 6179200 Holder complete with locking nu
094 2000700 Screw TCB M5x10 ZnCr
095 2016000 Cage nut M5 ZnCr
700 5157301 Gas boiler block
705 5071002 Complete casing without control
710 5072502 L.P.G. conversion kit
715 5095419 Complete control panel
717 5095420 Complete control panel
720 6223602 SIT gas valve coils (2 pieces)
721 6027604 Flying lead
722 6127201 Main cable L=2000
723 6269800 Ignition cable
724 6186560 Ionisation electrode cable L=80
725 6245306 Gas valve connector
727 6260933 Control box 4 pole fem. cable c
728 6260945 Control box 7 pole fem. cable c
729 6259501 Air/Smoke test pressure point
730 6233507 Fuse F3,15A 250V
731 6177213 Aluminium pipe L=830
