Q-Tech QSW-2800 [199/415] Arp guard configuration

+7(495) 797-3311 www.qtech.ru

Москва, Новозаводская ул., 18, стр. 1

185

25.2 ARP GUARD Configuration

Task List

1. Configure the protected IP address

Command

Explanation

Port configuration mode

arp-guard ip <addr>

no arp-guard ip <addr>

Configure/delete ARP GUARD address
