FLIR f=6,5 mm. (80°) для T6xx [4/5] Mechanical drawings
![FLIR f=6,5 mm. (80°) для T6xx [4/5] Mechanical drawings](/views2/1625528/page4/bg4.png)
6,36in
161,6mm
2,64in
67mm
8,46in
214,8mm
9,41in
239,1mm
4,5in
114,4mm
4,78in
121,4mm
For additional dimensions see page 1
Camera with Lens IR f=6,5 mm (80°)
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
2(9)
T127424
Basic dimensions FLIR T6xx
CAHA
2012-04-19
R&D Thermography
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Size
A
1:2
Scale
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
-
