Mehrstufi ge vertikale In-line
Kreiselpumpe
Baureihe IN-VB 60 / IN-VB-S 60
Vertical multistage inline
centrifugal pump
Series IN-VB 60 / IN-VB-S 60
Motordaten / Motor data
P [kW] 4,00 5,50 7,50 11,00 15,00 18,50 22,00 30,00 37,00 45,00
I
N
[A] 3~ 400 V 7,70 10,10 13,20 21,00 28,20 33,60 39,50 51,80 63,50 76,00
I
max.
[A] 3~ 400 V 8,80 14,40 17,60 27,30 32,00 42,20 46,30 57,20 70,20 85,00
Anschlüsse und Leistungsbereich / Connections and performance range
IN-VB 60 /
IN-VB-S 60
Anschlüsse
Connections
max.
Nenndruck
max nominal
pressure
min./max.
Temperatur
min/max
temperature
max. Umgebungs-
temperatur
max ambient
temperature
bis / to
- 90-2
Anschlussfl ansche DN 100 nach DIN(-EN)
(Gegenfl ansche lieferbar gegen Mehrpreis)
Connecting fl anges DN 100 to DIN(-EN)
(counter fl anges available at an extra charge)
PN 25 -15 – +100 °C 40 °C
Materialspezifi kation IN-VB 60
Pumpengehäuse Edelstahl 1.4308
Mantel Edelstahl 1.4301
Leitapparate Edelstahl 1.4301
Oberplatte Edelstahl 1.4301
Laufräder Edelstahl 1.4301
Wellenhülse Edelstahl 1.4301
Welle Edelstahl 1.4057
Lager Aluminium Oxid
Wellenschutzhülse Wolframcarbid
Fußplatte Sphäroguss JS 1030
Laterne Grauguss JL 1040
Stopfen Edelstahl 1.4301
Elastomere EPDM
Gleitringdichtung
Bis IN-VB 60-40-2 Kohle / SiC
Ab IN-VB 60-40 SiC / Kohle
Materialspezifi kation IN-VB-S 60
Pumpengehäuse Edelstahl 1.4408
Mantel Edelstahl 1.4404
Leitapparate Edelstahl 1.4404
Oberplatte Edelstahl 1.4404
Laufräder Edelstahl 1.4404
Wellenhülse Edelstahl 1.4404
Welle Edelstahl 1.4460
Lager Aluminium Oxid
Wellenschutzhülse Wolframcarbid
Fußplatte Sphäroguss JS 1030
Laterne Grauguss JL 1040
Stopfen Edelstahl 1.4404
Elastomere VITON
Gleitringdichtung
Bis IN-VB-S 60-40-2 Kohle / SiC
Ab IN-VB-S 60-40 SiC / Kohle
Material specifi cation IN-VB 60
Pump casing AISI CF8
Sleeve AISI 304
Diffusers AISI 304
Top plate AISI 304
Impellers AISI 304
Shaft protection bush AISI 304
Shaft AISI 431
Bearings Aluminium oxide
Shaft protection sleeve Tungsten carbide
Support plate Cast iron
Bracket Cast iron
Plug AISI 304
Elastomeres EPDM
Mechanical seal
Up to IN-VB 60-40-2 Carbon/Silicium carbide
From IN-VB 60-40 Silicium carbide/carbon
Material specifi cation IN-VB-S 60
Pump casing AISI CF8M
Sleeve AISI 316 L
Diffusers AISI 316 L
Top plate AISI 316 L
Impellers AISI 316 L
Shaft protection bush AISI 316 L
Shaft AISI 329
Bearings Aluminium oxide
Shaft protection sleeve Tungsten carbide
Support plate Cast iron
Bracket Cast iron
Plug AISI 316 L
Elastomeres VITON
Mechanical seal
Up to IN-VB-S 60-40-2 Carbon/Silicium carbide
From IN-VB-S 60-40 Silicium carbide/carbon
32
