Adjusting the fastening torque

(screwdriver mode "

Fig.9

The fastening torque can be adjusted in 21 steps by

turning the adjusting ring so that its graduations are

aligned with the pointer on the tool body.

First, slide the action mode change lever to the position

symbol.

The fastening torque is minimum when the number 1 is

aligned with the pointer, and maximum when the

marking is aligned with the pointer. The clutch will slip at

various torque levels when set at the number 1 to 21.

Before actual operation, drive a trial screw into your

material or a piece of duplicate material to determine

which torque level is required for a particular application.

NOTE:

• The adjusting ring does not lock when the pointer

is positioned only halfway between the

graduations.

ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before carrying out

any work on the tool.

Installing side grip (auxiliary handle)

Fig.10

Always use the side grip to ensure operating safety.

Insert the side grip so that the groove on the arm fit in

one of the counter parts on the tool. Then tighten the

grip by turning clockwise.

Depending the operations, you can install the side grip

either right or left side of the tool.

Installing or removing driver bit or drill bit

Fig.11

Turn the sleeve counterclockwise to open the chuck

jaws. Place the bit in the chuck as far as it will go. Turn

the sleeve clockwise to tighten the chuck. To remove

the bit, turn the sleeve counterclockwise.

Installing bit holder

Fig.12

Fit the bit holder into the protrusion at the tool foot on

either right or left side and secure it with a screw.

When not using the driver bit, keep it in the bit holders.

Bits 45 mm long can be kept there.

Adjustable depth rod

Fig.13

The adjustable depth rod is used to drill holes of uniform

depth. Loosen the clamp screw, set to desired position,

then tighten the clamp screw.

Hook

Fig.14

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool.

To install the hook, insert it into a groove in the tool

housing on either side and then secure it with a screw.

To remove, loosen the screw and then take it out.

OPERATION

Fig.15

Hammer drilling operation

CAUTION:

• There is a tremendous and sudden twisting force

exerted on the tool/bit at the time of hole break-

through, when the hole becomes clogged with

chips and particles, or when striking reinforcing

rods embedded in the concrete. Always use the

side grip (auxiliary handle) and firmly hold the tool

by both side grip and switch handle during

operations. Failure to do so may result in the loss

of control of the tool and potentially severe injury.

First, slide the action mode change lever so that it

points to the

marking. The adjusting ring can be

aligned in any torque levels for this operation.

Be sure to use a tungsten-carbide tipped bit.

Position the bit at the desired location for the hole, then

pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.

Do not apply more pressure when the hole becomes

clogged with chips or particles. Instead, run the tool at

an idle, then remove the bit partially from the hole. By

repeating this several times, the hole will be cleaned out

and normal drilling may be resumed.

Blow-out bulb (optional accessory)

Fig.16

After drilling the hole, use the blow-out bulb to clean the

dust out of the hole.

Screwdriving operation

First, slide the action mode change lever so that it points

to the

marking. Adjust the adjusting ring to the proper

torque level for your work. Then proceed as follows.

Place the point of the driver bit in the screw head and

apply pressure to the tool. Start the tool slowly and then

increase the speed gradually. Release the switch trigger

as soon as the clutch cuts in.

NOTE:

• Make sure that the driver bit is inserted straight in

the screw head, or the screw and/or bit may be

damaged.

• When driving wood screw, predrill a pilot hole 2/3

the diameter of the screw. It makes driving easier

and prevents splitting of the workpiece.
