Ada Cube 3-360 GREEN Professional Edition A00573 [2/26] Horizontal line 360 2 vertical lines 360

Laser level ADA CUBE 3-360 Green is an up-to-date functional and multi-

prism device designed for indoor and outdoor performance.

SPECIFICATIONS

Laser beam ................................................

Horizontal line 360°/2 vertical lines 360

Light sources ........................................... 3 laser diodes with laser emission

wave length of 515 nm

Laser safety class . ................................. Class 2, <1mW

Accuracy . .................................................... ±3mm/10m

Self-leveling range ..................................... ±4°

Operating range with/without receiver . .... 230/130 ft (70/40 m)

Power source ... Li-ion battery 3.7 V /

3xAA 1,5V

Tripod thread . ............................................ 2x1/4”

Operating temperature ........................... -5°C +45°C

Weight .................................................. 1,01 lb (460 g)

*depends on illumination

APPLICATION

FUNCTIONAL DESCRIPTION

1. 360

horizontal line and 2 vertical laser lines 360

2. Quick self-leveling: when line accuracy is out of the range the laser

line ashes and the warning sound is produced.

3. Compensator locking system for safe transportation.

4. Intermediate compensator locking system for slope operation.

5. Indoor and outdoor performance function.

English

LASER LINES
