ENGLISHen

metals, asbestos. Other known diseases are e.g.

allergic reactions, respiratory diseases. Do not let

dust enter the body.

Observe the relevant guidelines and national

regulations for your material, staff, application and

place of application (e.g. occupational health and

safety regulations, disposal).

Collect the particles generated at the source, avoid

deposits in the surrounding area.

Use suitable accessories for special work. In this

way, fewer particles enter the environment in an

uncontrolled manner.

Use a suitable extraction unit.

Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits,

- use an extraction unit and/or air purifiers,

- ensure good ventilation of the workplace and keep

clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

See page 2.

1 Hexagon socket attachment for hexagon

screwdriving bits*

2 Locking sleeve*

3 Rotation selector switch / Transporting safety

device

4 Trigger

5 Handle (gripping surface)

6 LED light

For working on dimly lit areas. The LED lights

light up when the machine is switched on.

7 Setting wheel for preselecting rotational speed

and tightening torque

8 Battery pack *

9 Battery pack release button

10 Capacity indicator button *

11 Capacity and signal indicator *

12 Belt hook (attach as shown) *

* depending on the features / model

Remove the battery pack from the machine

before any adjustment or maintenance is

carried out. Before fitting the battery pack, make

sure that the machine is switched off.

6.1 Battery pack

Charge the battery pack before use (8).

If performance diminishes, recharge the battery

pack.

The ideal storage temperature is between 10°C and

30°C.

"Li-Power, LiHD" li-ion battery packs have a

capacity and signal indicator: (11)

- Press the button (10), the LEDs indicate the

charge level.

- If one LED is flashing, the battery pack is almost

flat and must be recharged.

Removal:

Press the battery pack release (9) button and pull

the battery pack (8)

forwards.

Inserting:

Slide in the battery pack (8) until it engages.

6.2 Setting the direction of rotation, engag-

ing the transporting safety device

(switch-on lock)

Do not actuate the rotation selector switch or

engage the transportation lock (3) unless the

motor has stopped completely!

Actuate the rotation selector switch / Engage the

transportation lock (3)

R = Right rotation set

(insert screws)

L = Left rotation set

(remove screws)

0 = Central position: transportation lock setting

(switch-on lock)

6.3 Switching on and off

Switching on: press the trigger switch (4).

Switching off: release the trigger switch (4).

6.4 Speed / tightening torque

The speed and tightening torque are connected

directly. The lower the speed, the lower the

tightening torque.

The tightening torque is influenced in two ways:

1) Preselect operating mode/desiredtightening

torque at the setting wheel (7):

= max. tightening torque (power mode)

= adjustable tightening torque

= especially for self-cutting screws: at the

beginning high speed (for drilling) and later low

speed (for tightening the screw).

2) Stepless adjustment of the tightening torque:

The speed and tightening torque can be adjusted

steplessly in any position of the setting wheel by

pressing the trigger (4) firmly or lightly, thus

adapting to working conditions.

Recommendation: determine the correct setting

by carrying out trial screwdriving.

6.5

Changing screwdriving bit

for

SSD...

Inserting screwdriving bit: Slide locking sleeve

(2) forward and insert screwdriving bit as far as the

stop. Release locking sleeve (2).

Pull on the screwdriver bit to check that it is

correctly seated.

Removing screwdriving bit: Slide locking sleeve

(2) forward and remove screwdriving bit.

5. Overview

6. Initial Operation/Setting
