Indesit W 104 T [44/68] Fig 1 fig 2
![Indesit W 104 T [44/68] Fig 1 fig 2](/views2/1063140/page44/bg2c.png)
Model
W 104 T
Dimensiuni
Lãþime 59,5 cm
Înãlþime 85 cm
Adãncime 52,5 cm
Capacitate de
încãrcare
De la 1 la 5 Kg
Conexiuni electrice
Tensiune 220/230 V; Frecvenþã 50 Hz
Putere maximã absorbitã 1850 W
Conexiuni hidraulice
Presiune maximã 1 MPa (10 bari)
Presiune minimã 0,05 MPa (0,5 bar)
Capacitatea maºinii 40 de litri
Viteza de centrifugare
Pânã la 1000 rpm
Programe de control
conforme normei
IEC456
Programul 3; Temperatura
60°
C; °°Efectuat cu 5 Kg de încãrcãturã.
Aceastã aparaturã este conformã urmãtoarelor Directive Comunitare:
- 73/23/CEE din data de 19/02/73 (Tensiune Joasã) ºi modificãrii ulterioare
- 89/336/CEE din data de 03/05/89 (Compatibilitate Electromagneticã) ºi modificãrii ulterioare.
Caracteristici tehnice
41
Instrucþiuni de instalare ºi folosire
Verificarea periodicã a pompei de evacuare ºi a garniturii de cauciuc.
Maºina de spãlat rufe Indesit pe care tocmai aþi achiziþionat-o este echipatã cu o pompã de auto-curãþire ºi nu necesitã
o verificare ºi întreþinere periodicã a pompei. Chiar ºi in aceste condiþii, accidental pot pãtrunde în pompã mici obiecte
cum ar fi: monede, agrafe de pãr, nasturi, etc. Pentru a evita distrugerea pompei, aceste mici obiecte se opresc într-un
spaþiu special destinat, aflat în partea finalã a pompei.
Pentru a avea acces la acest spaþiu, trebuie sã îndepãrtaþi panoul frontal
aflat la baza maºinii cu ajutorul unei ºurubelnite. (fig. 1). Dupã aceasta,
rotiþi în sens opus acelor ceasornicului (fig. 2) ºi verificaþi dacã s-au
adunat obiecte mici.
Garnitura de cauciuc.
Verificaþi garnitura de cauciuc cel puþin odatã pe an, iar dacã observaþi
crestãturi sau alte deficienþe, înlocuiþi-o imediat.
Atenþie: Operaþiunea de întreþinere descrisã mai sus (precum ºi orice alta operaþiune de întreþinere) trebuie efectuatã doar dupã
încheierea ciclului de spãlare. În acest moment scoateti ºtecherul din prizã ºi respectaþi instrucþiunile de mai sus. La deºurubarea
capacului va curge puþinã apã. Înainte de fixarea panoului, dupã ce aþi terminat operaþiunea de întreþinere, asiguraþi-vã cã aþi înºurubat
capacul în mod corect, pentru a nu exista posibilitatea scurgerilor.
Fig. 1
Fig. 2
