ENGLISHen

The workpiece must lay flat and be secured against

slipping, e.g. using clamps. Large workpieces must

be sufficiently supported.

Damaged, eccentric or vibrating tools must not be

used.

Ensure that the spot where you wish to work is free

of power cables, gas lines or water pipes (e.g.

using a metal detector).

Avoid damage to gas or water pipes, electrical

cables and load-bearing walls (static).

Pull the plug out of the socket before making any

adjustments, converting or servicing the machine.

A damaged or cracked additional handle must be

replaced. Never operate a machine with a defective

additional handle.

Prior to each use, check if there are parts missing,

worn, broken, torn or damaged. Do not use a

defective or incomplete guard.

Use only the supplied clamping devices.

Reducing dust exposure:

WARNING - Some dust created by power

sanding, sawing, grinding, drilling, and other

construction activities contains chemicals known to

cause cancer, birth defects or other reproductive

harm. Some examples of these chemicals are:

- Lead from lead-based paints,

- Crystalline silica from bricks and cement and

other masonry products, and

- Arsenic and chromium from chemically treated

lumber.

Your risk from these exposures varies, depending

on how often you do this type of work. To reduce

your exposure to these chemicals: work in a well-

ventilated area, and work with approved safety

equipment, such as those dust masks that are

specially designed to filter out microscopic

particles.

This also applies to dust from other materials such

as some timber types (like oak or beech dust),

metals, asbestos. Other known diseases are e.g.

allergic reactions, respiratory diseases. Do not let

dust enter the body.

Observe the relevant guidelines and national

regulations for your material, staff, application and

place of application (e.g. occupational health and

safety regulations, disposal).

Collect the particles generated at the source, avoid

deposits in the surrounding area.

Use suitable accessories for special work. In this

way, fewer particles enter the environment in an

uncontrolled manner.

Use a suitable extraction unit.

Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream towards yourself or nearby

persons or towards dust deposits,

- use an extraction unit and/or air purifiers,

- ensure good ventilation of the workplace and keep

it clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash protective clothing. Do not blow,

beat or brush protective gear.

See page 2.

1 Angle grinder lever (for attaching and adjusting

the protective cover)

2Extraction guard

3 Pull machine only in direction of arrow

4 Angle grinder handle *

5 Pushbutton switch*

6 Electronic signal indicator *

7 Extractor connection piece

8 Side handle (of the angle grinder) *

9 Extension piece

10 Spindle locking button (of the angle grinder) *

11 Wheels (for placing on the workpiece)

12 Arrow indicating direction of rotation (direction

of rotation of the diamond cutting disc)

13 Spindle (of the angle grinder) *

14 Support flange (of the angle grinder) *

15 two spacer discs

16 Diamond cutting disc *

17 two-hole adjusting nut

18 two-hole spanner

* not in scope of delivery/ depends on equipment

Prior to any conversion work: pull the mains

plug out of the socket. The machine must be

switched off and the spindle at a standstill.

Before commissioning, check that the rated

mains voltage and mains frequency stated on

the type plate match your power supply.

Always install an RCD with a maximum trip

current of 30 mA upstream.

6.1 Attaching the extraction guard to the

angle grinder

See page 2, Fig. A and Fig. B.

1. Push and hold the lever (1).

2. Place the extraction guard (2) in the position

shown on the angle grinder (see page 2, Fig. A).

3. Press the lever (1) and turn the extraction guard

(2) so that the angle grinder is pointing in the

direction shown (see page 2, Fig. B).

4. Release the lever (1) and turn the extraction

guard (2) until the lever (1) engages.

5. Make sure that the guard is placed securely: The

lever (1) must engage and you should not be

able to turn the extraction guard (2).

Attaching the additional handle

Always work with the additional handle (8)

attached! Firmly screw in the additional handle

(8) together with the extension piece (9) on the

angle grinder.

6.2 Attaching the dust extraction

Only work with adequate dust extraction:

Connect a suitable vacuum (in line with

national regulations) to the extraction sockets (7).

5. Overview

6. Initial Operation
