-14-
EN
APPLICATION TABLE
Cleaningmethod Use Attachments Filteringsystem
Dry vacuuming
Rugs and hard surfaces,
furnishings and car uphol-
stery, crevices, corners,
cars, areas that are difficult
to access in general
“Magic Brush” ⑭, fabric
nozzle ⑩, crevice nozzle
⑦, sfloor brush ⑧, parquet
floor attachment ⑨
500 cc water in the contai-
ner (G)
Washing
Deep-down cleaning and
removal of stains from rugs,
carpets and upholstery,
cleaning of hard surfaces
and windows
Spray ⑥ + “Magic Brush”
⑭, kit for cleaning glass
and windows ⑫
500 cc water in the con-
tainer (G), water in the
container (X).
Cleaning up liquids
Cleaning up of water-based
liquids such as fruit juice,
coffee, water, etc. ..., from
rugs and hard surfaces
“Magic Brush” ⑭, kit for
cleaning glass and windows
⑫
500 cc water in the contai-
ner (G).
Washing with detergent
Cleaning with the detergent
to remove dirt and add a
touch of fragrance to the
room.
Spray ⑥ + “Magic Brush”
⑭, kit for cleaning glass
and windows ⑫
500 cc water in the con-
tainer (G), water in the
container (X), detergent in
the container (E).
INSTRUCTIONS FOR USE
Usingtheapplianceforthefirsttime
Fill the container (E) with the detergent supplied or with another detergent, as long as it is non foaming. Fill the container (X)
with water, connect the nozzle to the appliance body (without attachments), set the steam adjustment dial to MAX, switch on
the water dispenser button (U) and dispense water for 5 seconds by pressing the button on the nozzle.
Reset the dial to dose the detergent to a middle position.
The appliance is now ready to be used.
• Turn the lever (C) to open the cover clockwise or anticlockwise to release the appliance (
1
).
• Open the cover (D) lifting it upwards by the special hand grip (B) (
2
).
• The item acting as a dry cleaner with water filter needs an initial 500 cc, which is equivalent to 5 glasses of water in the
tank (G) (
3
).
• The water in the container (G) serves to trap the impurities in the air.
• Close the cover (D) and lock it in place by turning the lever (C) in the opposite direction to opening and until it is perfectly
aligned with the hand grip (B), making sure this is in the closed position.
• When using the appliance for washing, the container (X) needs to be filled with water, first removing the filler cap (V) (
4
).
NOTE:Itisalsopossibletoremovethecontainer(X),pullingitupwardsbythespecialhandle(Z),andto
fillitunderarunningtap.
• Refit the container (X) by pressing it down gently as far as it will go and then making sure it has been inserted correctly.
• In the case of stubborn stains, should you wish to wash using the detergent provided ⑯, insert this in the relevant container
(E) after first lifting the cover (D) and removing the cap (F) (
5
).
• Insert the suction hose ① into the relevant inlet (A) and lock it in position by gently pressing it down until the top tab clicks
into place (
6
).
• In the same way, to remove the hose ① it is necessary to press the tab down and pull the hose upwards.
• Fit the required attachment onto the grip of the suction hose ① according to the type of cleaning required and the surface
to be cleaned. Insert the attachment and lock it into place (
7
).
• Pull out the power cord completely and plug it into the mains socket.
• Press the on/off switch (N) with your foot to switch on the suction function (
8
).
• The suction power can be adjusted using the dial (T) on the top of the appliance ③ or opening the valve on the suction
hose handgrip (
9
).
