EN
Attention!
Before using the appliance please read the contents of this instruction.
Attention!
Children of 8 years old and upward intend this appliance for use
and persons with reduced physical, sensory or mental capabilities,
or lack of knowledge, unless a person responsible for their safety
has given them supervision or instruction concerning the use of the
appliance. Children should be supervised to ensure that they do not
play with the appliance. Cleaning and service of the device shouldn’t
to be made by children without supervision.
Safety requirements
Base on type of protection from electric shock the fans relate to the devices
of class ll (220-240V/50Hz) or class III (12V/50 Hz). The climate category
«moderately cold» Type «4» (УХЛ4). The level of protection against solid objects
and water is IP 24.
Attention!
Specialists, who have a special allowance for such types of work, shall
do connection of the fans to power supply. The temperature of fan
exploitation cannot exceed the indicated range (from +1C to +40C).
Avoid the installation of the fan to one ventilation main line with smoke-deflecting
pipe from devices, having fuel burners. In case of maintenance diagnostics, turn o
the automatic breaker (S1 in OFF position) and call an electrician.
Attention!
All actions for connection, set up, maintenance and repair of the product
have to be carried out only at mains voltage removed (S1 in OFF position).
One-phase main, to which the fan is connected, must correspond to the norms in
force. Stationary electric wiring must be equipped with an automatic circuit breaker
(S1 in the scheme). The connection is carried out through the switch (S2 in the
diagram) that is built into the stationary wiring. The gap between switch contacts
at all poles must be not less than 3 mm. In the option «-02» the switch (S3 on the
scheme) is built in the fan. Before installation, it is necessary to make sure that there
is no visible damage of impeller, case, grill, and the flow passage of the case has no
any extraneous things, which may damage impeller blades.
Сorrect use
Axial duct domestic electric fan, axial duct domestic removable electric fan is
designed to remove odors and excess moisture from toilets, bathrooms and other
small rooms, required ventilation.
Attention!
For the purposes of maintenance or complete replacement of the
equipment, all fans must have detachable fixing.
MAIN TECHNICAL CHARACTERISTICS
Characteristics
COMFORT 4
COMFORT 5
DISC 4
DISC 5
FAVORITE 4
FAVORITE 5
FLOW 4
FLOW 5
FLOW 150
FLOW 6
E 100
E 125
E 150
NEO 4
NEO 5
NEO 6
ERA 4
ERA 5
ERA 6
PROFIT 4
PROFIT 5
PROFIT 150
PROFIT 6
EURO 4
EURO 5
EURO 6
EURO 4А
EURO 5А
EURO 6А
Flange diameter
(mm)
100 125 100 125 100 125 100 125 150 160 100 125 150 100 125 150 100 125 150 100 125 150 160 100 125 150 100 125 150
Eciency (m3/h) 95 180 80 130 95 180 107 190 280 300 90 140 250 90 140 250 97 183 290 107 190 280 300 85 130 230 85 130 230
Power
сonsumption (W)
16 18 16 20 16 18 14 18 20 22 14 16 16 14 16 16 14 16 16 14 18 20 22 14 14 14 18 16 16
Noise level (dB) 35 36 35 36 35 36 35 36 37 38 35 36 38 35 36 38 35 36 38 35 36 37 38 35 36 38 35 36 38
Weight (kg) 0,55 0,65 0,5 0,58 0,55 0,65 0,5 0,6 0,9 0,95 0,55 0,65 0,77 0,55 0,65 0,77 0,5 0,55 0,7 0,38 0,45 0,65 0,7 0,6 0,8 1,0 0,6 0,8 1,0
The fans are designed for connection to AC mains voltage 220-240 V (for a 12V fan with 12V option), frequency 50 Hz.
