11
High pressure cleaners
• Low voltage and delayed
Total Stop:
To avoid quick and multiple
start and shut down of the motor/pump group
whenever the gun trigger is pulled and released,
this disposal delays of about 15 seconds the
machine shut down. Prevention, energy saving,
top safety and pump longer life.
• Motor low rotation speed:
The electric motor transfers the
same number of revolutions to
the pump. With a 4 poles motor there is a lower
rotation speed of the components (1400 RPM
in case of 50Hz or 1750 RPM in case of 60 Hz)
granting longer pump life. Extending lifetime
solution.
Cold water high-pressure cleaner Vanguard line
lifetime. What determines the pump quality is the
quality of the project itself (linear or axial) and of
the components used; for this reason Lavorwash
decided to develop both technologies, taking into
consideration a design that grants margin of safety
and reliability.
• Linear pump:
The movement of the (3) pistons occurs
through a system of connecting rods
and crankshaft. The longitudinal axle
of the pistons (placed at the same level or linear) is
perpendicular to the motor rotation axle. It is more
versatile to bear high delivery rates (from 21 l/
min) and it has a better self priming.
• Water cooled motor:
Water flows through the S. S. coil
around the motor, this allows a
better thermal exchange (and so a
cooling) than air also in those countries where
inlet water could reaches 60°C. This allows a drop
in operating temperature of the motor and pump
mechanical elements, granting a better reliability
and longer life.
• Total Stop:
Releasing the gun trigger the
pump stops automatically avoiding
element damages during the by-pass phase.
Pulling the trigger, the high-pressure cleaner starts
automatically. Max pump protection.
