9
INSTALLATION INSTRUCTIONS, MAINTENANCE
AND USING THE DISPOSER
Before installing the product, read everything care-
fully. Installation, maintenance and use manual. Be-
fore starting work determine which tools, materials,
and equipment you need.
Before installing the disposer, make sure that you
have all the necessary parts of the product.
REQUIRED TOOLS AND MATERIALS:
screwdriver, Hinged pliers, insulation tape, protec-
tive glasses
REQUIRED INSTRUMENTS, MATERIALS AND
OPTIONAL EQUIPMENT:
a Phillips screwdriver, a drainage drill, electrical
terminal 9.5 mm, threaded nuts (2), siphon 38 mm,
drill 25 mm, hammer, hacksaw, water hose clamp,
pipe pliers, copper grounding wire, dishwasher
drainage pipe kit, electric switch, extension pipe
1. DESCRIPTION OF THE PRODUCT (FIG.1.1)
Assembly unit
1. Stopper
2. Washing ange
3. Rubber gaskets (2)
4. Support ring
5. Mounting ring
6. Screws
7. Locking ring
8. Sound attenuating screen Disposer
9. Installation gasket/ protective reector
10. Eyelets
11. Lower mounting ring
12. Drain the dishwasher
13. Outlet opening Drainage system
14. Mounting Screws
15. Rubber gasket
16. Flange
17. Drain pipe with a knee
2. DISCONNECTION OF THE DROP HORN AT-
TENTION!
At the time of installation of the device is
recommended Wear safety glasses. Loosen the
nut (1) on the top of the water trap (4) with a pipe
wrench (Fig. 3.1). relative humidity not more than
80%. Loosen the nut (2) on the top of the extension
pipe. Remove the extension pipe.
Loosen the nut (3) at the bottom of the washing
ange.
Push the washing ange upwards through drain
hole of the sink and remove it (Fig. 3.2).
CLEAN THE WASH FAN WRAPPING PLACE FROM THE
SEALANT OR THE GARBAGE.
English
oder reparieren Sie das Produkt, wenden Sie sich an
einen autorisierten Händler Service Center oder zu
Ihrem Händler.
Die Garantie erlischt in folgenden Fällen:
- wenn das Produkt mit Beeinträchtigungen ver-
wendet wurde Anforderungen dieses Handbuchs
- in Gegenwart von Spuren der Önung des Körpers
des Produkts zur Selbstreparatur
Weitere Informationen zu den Garantiebedingun-
gen nden Sie in der Garantie Coupon.
