Nilfisk MH 2C-190/780 X 400/3/50 [19/22] Technical data

Nilfisk MH 2C-190/780 X 400/3/50 [19/22] Technical data
NEPTUNE 1, NEPTUNE 2
NEPTUNE 2 Special
Description General 1-22 EU
230/50/16
1-22 GB
230/50/13A
2-20 US
115/1/60/20
2-25 GB
230/1/50/13
2-25X GB
230/1/50/13
Data Tol. (±) Nom + Tol/- Tol Nom + Tol/- Tol Nom + Tol/- Tol Nom + Tol/- Tol Nom + Tol/- Tol
Pressure Pwork @ Cylinder
Head(bar)
10% 110 +11/-11 110 +11/-11 69 +7/-7 90 +9/-9 90 +9/-9
Flow. Qiec (l/h) 10% 540 +54/-54 540 +54/-54 568 +57/-57 640 +64/-64 640 +64/-64
Flow. Qmax (l/h) 10% 600 +60/-60 600 +60/-60 636 +64/-64 670 +67/-67 670 +67/-67
Temperature t max, hotwater (°C) 80 80 80 80 80
Temperature t max , steam (°C) NA NA 150 150 150
Elec. V/Ph/Hz +/-6% 230/1~/50 230/1~/50 115/1~/60 230/1~/50 230/1~/50
Power Consumption (kW) 2,8 2,8 2,1 2,9 2,9
Fuel tank (l) 17 17 17 17 17
Detergent tank (l) 5 5 5 5 5
Noise level 1m ( dBA) 74 74 77 76 76
Recoil forces with standard lance
(10deg,) (N)
17,6 17,6 12,9 19 18,5
Vibration ISO 5349 (m/s²) ≤2,5 ≤2,5 ≤2,5 ≤2,5 ≤2,5
Weight - Machine alone (kg) 91 91 97 97 99
Size - Machine alone (mm) 607x688x1000 607x688x1000 607x688x1071 607x688x1000 607x688x1071
Fuse size (A) 16 13 20 13 13
Max. inlet pressure (bar) 6 6 10 10 10
Max. Inlet temperature (°C) 40 40 40 40 40
Description General 2-26 EU
230/1/50/16
2-26X EU
230/1/50/16
2-26 EU Special
230/1~/50
2-26X EU Special
230/1~/50
2-30 EU Special
400/3~/50
Data Tol. (±) Nom + Tol/- Tol Nom + Tol/- Tol Nom + Tol/- Tol Nom + Tol/- Tol Nom + Tol/- Tol
Pressure Pwork @ Cylinder
Head(bar)
10% 145 +15/-15 145 +15/-15 140 +14/-14 140 +14/-14 155 +16/-16
Flow. Qiec (l/h) 10% 530 +53/-53 530 +53/-53 560 +56/-56 560 +56/-56 600 +60/-60
Flow. Qmax (l/h) 10% 600 +60/-60 600 +60/-60 600 +60/-60 600 +60/-60 660 +66/-66
Temperature t max, hotwater (°C) 80 80 80 80 80
Temperature t max , steam (°C) 150 150 ? ? ?
Elec. V/Ph/Hz +/-6% 230/1~/50 230/1~/50 230/1~/50 230/1~/50 400/3~/50
Power Consumption (kW) 3,4 3,4 3,4 3,4 3,8
Fuel tank (l) 17 17 17 17 17
Detergent tank (l) 5 5 5 5 5
Noise level 1m ( dBA) 77 77 74 74 74
Recoil forces with standard lance
(10deg,) (N)
20,8 20,6 21,8 21,6 24,6
Vibration ISO 5349 (m/s²) ≤2,5 ≤2,5 ≤2,5 ≤2,5 ≤2,5
Weight - Machine alone (kg) 97 99 97 99 97
Size - Machine alone (mm) 607x688x1000 607x688x1071 607x688x1000 607x688x1071 607x688x1000
Fuse size (A) 16 16 16 16 16
Max. inlet pressure (bar) 10 10 10 10 10
Max. Inlet temperature (°C) 40 40 40 40 40
9.4 Technical data
