227
Monitoring and Configuring the Printer
SNMP
The Ethernet interface includes the Simple Network Management Protocol (SNMP) agent for UDP and IPX.
Using the SNMP manager, you can obtain printer data.
The default community name is "public". Using this community name, you can obtain MIB data.
Supporting MIB (SNMP v1/v2)
z
MIB-II
z
PrinterMIB
z
HostResourceMIB
z
RicohPrivateMIB
