Figure
Hard-floor brush
䡲 For cleaning hard floor coverings
(tiles, parquet flooring, etc.)
䡲 Connect the floor tool and the telescopic tube together.
Figure
Once you have switched off the vacuum cleaner, you can
use the parking aid on the back of the vacuum cleaner if
you wish to stop vacuuming for a short time.
To do this, slide the catch on the floor tool into the
groove on the back of the vacuum cleaner.
When the work is done
Figure
䡲 Unplug the vacuum cleaner.
䡲 Briefly pull the power cord and release. The cord rewinds
automatically.
Figure
To store or transport the vacuum cleaner, use the storage
aid on the underside of the vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide the catch
on the floor tool into the groove on the underside of the
vacuum cleaner.
Changing the dust bag and filters
Replacing the dust bag
Figure
If the dust bag change indicator lights up brightly and
evenly when the floor tool is lifted from the carpet and
the highest suction power is selected, the dust bag must
be changed, even though it may not yet be full. In this
case it is essential to change the dust bag due to the
type of material it contains.
First check that the nozzle, suction pipe and flexible hose
are not blocked, as this would also lead to the dust bag
change indicator being triggered.
Figure
Open the lid by moving the locking lever in the direction
of the arrow.
Figure
a) Seal the dust bag by pulling the sealing strip and then
remove it.
b) Insert a new dust bag into the holder and close the dust
bag compartment lid.
!
Caution: the lid will only close when the dust bag is
inserted.
19
18
17
16
15
14
13*
Vacuuming
Figure
The required suction power can be selected infinitely
variably by adjusting the slide control.
䡲 Lowest
suction range:
For vacuuming delicate fabrics,
e.g. curtains.
䡲 Low
suction range:
For daily vacuuming of lightly soiled floors.
䡲 Medium
suction range:
For vacuuming durable floor coverings, hard floors and
for heavily soiled surfaces.
䡲 High
suction range:
For vacuuming stubborn dirt and very heavily soiled
surfaces.
Figure
Adjusting the floor tool:
a) For vacuuming rugs
and carpets =>
b For vacuuming
hard floors =>
Caution!
Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.
Turbo brush
If your vacuum cleaner is equipped with a turbo brush,
please consult the accompanying instruction manual for
notes on its use and maintenance.
Figure Vacuuming with accessories
Attach the nozzles to the tube or handle as required:
a) Crevice nozzle for vacuuming crevices and corners, etc.
b) Upholstery nozzle for vacuuming upholstered furniture,
curtains, etc.
Figure
Pet hair tool
䡲 Floor tool for easy and thorough vacuuming of pet hair.
䡲 Push the telescopic tube into the connecting piece of the
pet hair tool until it engages.
Press on the locking collar and pull out the telescopic
tube to disconnect.
䡲 To clean, simply vacuum the tool using the suction
pipe/telescopic tube.
12*
11*
10
9
10
en
*
Dependent on model
