Nozzle Chart

PUMPS • UNLOADERS • GUNS • LANCES • ACCESSORIES

Litres / min

1 Gallon = 4.54 litres 1 bar = 14.5 psi

Pressure In Bar

Nozzle

Size 50 80 100 120 140 150 160 180 200 220 240 260 280 300 350 400 450 500

02 3.2 4 4.5 4.9 5.3 5.5 5.7 6 6.3 6.6 6.9 7.2 7.5 7.7 8.4 8.9 9.5 10

025 4 5 5.6 6.1 6.6 6.8 7.1 7.5 7.9 8.3 8.7 9 9.4 9.7 10.5 11.2 11.9 12.5

03 4.7 6 6.7 7.3 7.9 8.2 8.5 9 9.6 9.9 10.4 10.6 11.2 11.6 12.6 13.4 14.2 15

04 6.3 8 8.9 9.8 10.6 11 11.3 12 12.6 13.3 13.9 14.4 15 15.5 16.7 17.9 19 20

045 7.1 9 10.1 11 11.9 12.3 12.7 13.5 14.2 14.9 15.6 16.2 16.8 17.4 18.8 20.1 21.3 22.5

05 7.9 10 11.2 12.2 13.2 13.7 14.1 15 15.8 16.6 17.3 18 18.7 19.4 20.9 22.4 23.7 25

055 8.7 11 12.3 13.5 14.6 15.1 15.6 16.5 17.4 18.2 19.1 19.8 20.6 21.3 23 24.6 26.1 27.5

06 9.5 12 13.4 14.7 15.9 16.4 17 18 19 19.9 20.8 21.6 22.4 23.2 25.1 26.8 28.6 30

065 10.3 13 14.5 15.9 17.2 17.8 18.4 19.5 20.6 21.6 22.5 23.4 24.3 25.2 27.2 29.1 30.8 32.5

07 11.1 14 15.7 17.1 18.5 19.2 19.8 21 22.1 23.2 24.2 25.2 26.2 27.1 29.3 31.3 33.2 35

075 11.9 15 16.8 18.4 19.8 20.5 21.2 22.5 23.7 24.9 26 27 28.1 29 31.4 33.5 35.6 37.6

08 12.8 16 17.9 19.6 21.2 21.9 22.6 24 25.3 26.5 27.7 28.8 29.9 31 33.5 35.8 37.5 40

085 13.4 17 19 20.8 22.5 23.3 24 25.5 26.9 28.2 29.4 30.6 31.8 32.9 35.6 38 40.3 42.5

09 14.2 18 20.1 22 23.8 24.6 25.5 27 28.5 29.8 31.2 32.4 33.7 34.9 37.6 40.2 42.7 45

10 15.8 20 22.4 24.5 25.5 27.4 28.3 30 31.6 33.2 34.6 36.1 37.4 38.7 41.8 44.7 47.4 50

11 17.4 22 24.6 26.9 29.1 30.1 31.1 33 34.8 36.5 38.1 39.7 41.2 42.6 46 49.2 52.2 55

12 19 24 26.5 29.4 31.7 32.9 33.9 36 37.9 39.8 41.6 43.3 44.9 46.5 50.2 53.7 58.9 60

13 20.6 26 29.1 31.8 34.4 35.6 36.8 39 41.1 43.1 46 46.9 48.6 50.3 54.4 58.1 61.7 65

14 22.1 28 31.3 34.3 37 38.3 39.6 42 44.3 46.4 48.5 50.5 52.4 54.2 58.6 62.6 66.4 70

15 23.7 30 33.5 36.7 39.7 41.1 42.4 45 47.4 49.7 52 54.1 56.1 58.1 62.7 67.7 71.2 75

16 25.3 32 35.8 39.2 42.3 43.8 45.3 48 50.6 53.1 55.4 57.7 59.9 62 66.9 72 75.9 80

18 28.5 36 40.2 44.1 47.6 49.3 50.9 54 56.9 59.7 62.4 64.9 67.3 69.7 75.3 80.5 85.4 90

20 31.6 40 44.7 49 52.9 54.8 56.6 60 63.2 66.3 69.3 72.1 74.8 77.5 83.7 89.4 94.9 100

25 39.5 50 55.9 61.2 66.1 68.5 70.7 75 79.1 82.9 86.5 90.1 93.5 96.6 105 112 119 125

30 47.4 60 67.1 73.5 79.4 82.2 84.9 90 94.9 99.5 104 106 112 116 125 134 142 150

35 55.3 70 78.3 85.7 92.6 95.9 99 105 111 116 121 126 131 136 146 157 165 175

40 63.2 80 89.4 95 106 110 113 120 126 133 139 144 150 155 167 179 190 200

Example : For a pump rated at 180 bar, 21 litres / min use an 07 Jet
