Technical information

Explosion drawing and parts list

ST62 (6200500) ST62 BRUSH SANDER | Version A

Pos. Serial No. Code Description Quantity

44 6268650 CAPACITOR 1

45 6203155 SWITCH BUTTON 1

46 6203154 SWITCH SLIDE 1

47 6218046 BRUSH HOLDER 2

48 8578030 SCREW M4X8 TORX 4

49 6203934 PROTECTION COVER 1

50 6203935 NOZZLE 1

51 6203152 COVER 1

52 4679014 SCREW D.4X10 TX 3

53 6203156 CLAMP 1

54 8002043 CORD ARMOR 1

55 5400025 CORD ASS'Y 230V (EUROPE) 1

56 1699005 WRENCH 6 mm 1

57 8802479 HANDLE SET 1

58 6203153 DUST COLLECTOR ATTACHMENT 1

59 8578024 SCREW M.5X10 TORX 2

60 6246899 REAR ROLLER ASS'Y 1

61 6246890 HEAD ASS'Y 1

62 6246897 PROTECTION HOLDER ASS'Y 1

63 6224188 HANDLE SUPPORT 1

64 3178016 SCREW M.5X15 PH. 3

65 4380016 WASHER D.6.3X11.8X1 1

66 3774011 CUP SQUARE NECK BOLT M.6X15 1

67 6246898 FRONT ROLLER ASS'Y 1

68 6280084 WASHER D.27.8X19.5X1 1

69 6291214 NYLON BRUSH 1

69 6291215 BRASS BRUSH 1

69 6291216 SANDING BRUSH 1

69 6291217 SCOTCH BRUSH 1
