Technical information

Explosion drawing and parts list

RO156N (5600400) RO156N / RO1156T STRAIGHT GRINDER | Version G (From serial number 190068)

Pos. Serial No. Code Description Quantity

1 1199237 WRENCH 19 mm 1

4 1222023 COLLET NUT 1

5 1222084 SHORT COLLET D.6 1

5 1222085 SHORT COLLET D.1/4 1

7 1299238 SPANNER 11 1

19 5619317 LABEL 1

120 1204003 BEARING HOLDER 1

121 1210019 BALL BEARING 607 Z 1

122 1288012 RETAINING RING SW-15 1

123 1680026 WASHER D.4.3X9X0.8 2

124 1704084 WRENCH CLAMP 1

125 2015043 SWITCH 1

126 2045292 SET 2 BRUSH HOLDERS W/BRUSHES 230V 1

127 2079011 SCREW D.3.6X8 CL89Z 1

128 2310003 BALL BEARING 6002-ZZ 2

129 2323030 BEARING PROTECTOR 1

130 3504030 RUBBER PIN 2

131 4302025 CORD CLAMP 1

132 4679013 SCREW D.4X25 TX 2

133 5400025 CORD ASS'Y 230V (EUROPE) 1

134 5606243 FRONT HEAD (V1) 1

135 5622247 NUT 1

136 5622248 BUSHING 1

137 5651166 ARMATURE 230V 1

138 6478001 SCREW M.4X8 PH. 2

139 7903071 FAN GUIDE 1

140 8002043 CORD ARMOR 1

141 9202451 COVER 1

142 9202453 RIGHT COVER 1

143 9202454 LEFT COVER 1

144 9202455 TIE ROD 1

145 9202456 HOUSING 1

146 9202458 PUSH BUTTON 1

147 9202520 CLAMP 1

148 9217035 CARBON BRUSHES SET 1

149 9226155 BRUSH SPRING 2

150 9246310 ELECTRONIC CIRCUIT GR4 230V 1

151 9255162 STATOR 230V 1

152 9268299 CAPACITOR 1

153 9279018 SCREW D.4X40 (TX) 3

154 9279019 SCREW D.4X35 (TX) 4
