Climber 9.22/ Translation of the original instructions

PUTTING THE MACHINE INTO SERVICE

1) Check that the machine has not been damaged in transit.

2) Check the oil levels of the engine, hydrostatic transmission and final drive.

3) Check the tyre pressure:

– 1 BAR front wheels 13×50/6

– 1.5 BAR rear wheels 17×8.00-8

4) Check the battery voltage; it must be at least 12,5 Volts. If necessary, charge the battery with a

Change the engine oil and filter after the first 20 working hours. Check that there are no oil leaks or

loosen screws, especially those which fix the blade, the steering and the wheels. Adjust the tension of

the hydrostatic transmission belts (fig. 16).

INSTRUCTIONS FOR USE

BEFORE STARTING UP THE ENGINE

Before starting up the engine, always check that:

– the engine oil level is correct (fig. 2)

 the oil in the hydraulic engine is at the correct level (fig. 3)

 the forward level is in neutral position (fig. 1B, no. 2)

 the engine cooling intake grids are clean (fig. 5)

STARTING THE ENGINE

– Push the throttle half way in (fig. 1B, no.5).

– If the engine is cold, use the choke (fig. 1B, no.6). Turn the ignition key on the dashboard (fig.1, no. 7).

– Once the engine has started, turn off the choke and wait for a few minutes to allow the engine to warm

up.

– To switch off the engine put the ignition key in the STOP position (fig.1, no. 7).

Important: When moving the mower from one place to another, keep the cutter deck at the maximum

height setting.

STARTING WORK

– Choose the desired cutting height using the lever (fig. 1D, no. 8). Suitably accelerate the engine and

8
