2N5086 2N5087
TO-92
Plastic Package
2N5086_5087Rev_1 171103E
TO-92 Tape and Ammo Pack
For Lead Free Parts,
Device Part # will be
Prefixed with "T"
Adhesive Tape on Top Side
Flat side
Flat Side of Transistor and
Adhesive Tape Visible
2000 pcs./Ammo Pack
Label
Carrier
Strip
186
(7.3")
3
3
2
(
1
3
"
)
F
E
E
D
4
3
(
1
.
7
"
)
Ammo Pack Style
Tape Mechanical Data
A
A1
P
(p)
C1
C2
W2
Do
F2
F
P2
Po
F1
W1
Wo
W
H1
H2
H3
L
Ho
h1 h1
T
h
t
t1
h
ITEM
SYMBOL
SPECIFICATION
PULL - OUT FORCE (p) 6N
MIN. NOM.
BODY WIDTH
A1
4.0 4.8
BODY HEIGHT A 4.8
5.2
BODY THICKNESS T 3.9
4.2
COMPONENT ALIGNMENT SIDE VIEW
h
0 1.0
COMPONENT ALIGNMENT FRONT VIEW
h1 0 1.3
COMPONENT HEIGHT H1
23.25
LENGTH OF SNIPPED LEADS L
11.0
TOTAL TAPE THICKNESS t
1.2
CLINCH HEIGHT H3 3.0
LEAD PARALLELISM
| C1 - C2 |
0.22
MAX.
PITCH OF COMPONENT P
12.7
± 1.0
FEED HOLE PITCH Po
12.7
± 0.3
FEED HOLE CENTRE TO
COMPONENT CENTRE
P2
6.35
± 0.4
DISTANCE BETWEEN OUTER
LEADS F
5.08
+ 0.6
- 0.2
TAPE WIDTH W
18
± 0.5
HOLD-DOWN TAPE WIDTH Wo
6
± 0.2
HOLE POSITION W1
9
+ 0.7
- 0.5
HOLD-DOWN TAPE POSITION W2
0.5
± 0.2
LEAD WIRE CLINCH HEIGHT Ho
16
± 0.5
FEED HOLE DIAMETER Do
4
± 0.2
LEAD - TO - LEAD DISTANCE F1, F2
2.54
+ 0.4
STAND OFF H2 0.45 1.45
TOL .
- 0.1
All dimensions are in mm
3
*
4
*
5
*
1
*
*
2
At top of body
3
*
At top of body
4
*
t1 0.3 – 0.6 mm
5
*
Cumulative pitch error 1.0 mm/20 pitch
1
*
*
2
To be measured at bottom of clinch
REMARKS
NOTES
1.
2.
3.
4.
5.
6.
Maximum alignment deviation between
leads will not to be greater than 0.2mm.
Maximum non-cumulative variation
between tape feed holes shall not
exceed 1 mm in 20 pitches.
Holddown tape will not exceed beyond
the edge(s) of carrier tape and there
shall be no exposure of adhesive.
There will be no more than three (3)
consecutive missing components in a
tape.
A tape trailer, having at least three feed
holes are provided after the last
component in a tape.
Splices should not interfere with the
sprocket feed holes.
Continental Device India Limited
Data Sheet Page 4 of 5
