D - KIMWC00211-09EN - 14/58
Sound pressure levels EWWD-DJYNN, EWWD-DJYNN/A
Sound pressure level at 1 m from the in free field ( rif. 2 x 10
5
)
DJYNN DJYNN/A
63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz dBA
170 190
58 58 63,5 68,5 63 64 53 49,5
69,7
210 230
58 58 63,5 68,5 63 64 53 49,5
69,7
260 280
58 58 63,5 68,5 63 64 53 49,5
69,7
300 320
58 58 63,5 68,5 63 64 53 49,5
69,7
320 380
60 60 65,5 70,5 65 66 55 51,5
71,7
380 400
60 60 65,5 70,5 65 66 55 51,5
71,7
420 460
60 60 65,5 70,5 65 66 55 51,5
71,7
460 500
60 60 65,5 70,5 65 66 55 51,5
71,7
500 550
60 60 65,5 70,5 65 66 55 51,5
71,7
600 650
60 60 65,5 70,5 65 66 55 51,5
71,7
Note: Average sound pressure level rated in accordance to ISO 3744, free field semispheric conditions.
Sound pressure levels EWWD-DJYNN, EWWD-DJYNN/A with sound proof cabinet
Sound pressure level at 1 m from the in free field ( rif. 2 x 10
5
)
DJYNN DJYNN/A
63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz dBA
170 190
55.9 55.2 59.6 63.9 57.7 58.5 47.7 44.2
64.7
210 230
55.9 55.2 59.6 63.9 57.7 58.5 47.7 44.2
64.7
260 280
55.9 55.2 59.6 63.9 57.7 58.5 47.7 44.2
64.7
300 320
55.9 55.2 59.6 63.9 57.7 58.5 47.7 44.2
64.7
320 380
57.9 57.2 61.6 65.9 59.7 60.5 49.7 46.2
66.7
380 400
57.9 57.2 61.6 65.9 59.7 60.5 49.7 46.2
66.7
420 460
57.9 57.2 61.6 65.9 59.7 60.5 49.7 46.2
66.7
460 500
57.9 57.2 61.6 65.9 59.7 60.5 49.7 46.2
66.7
500 550
57.9 57.2 61.6 65.9 59.7 60.5 49.7 46.2
66.7
600 650
57.9 57.2 61.6 65.9 59.7 60.5 49.7 46.2
66.7
Note: Average sound pressure level rated in accordance to ISO 3744, free field semispheric conditions.
Sound pressure level correction factor EWWD-DJYNN, EWWD-DJYNN/A for different
distances
Distance (m)
DJYNN DJYNN/A
1 5 10 15 20 25
170 190
0 8.7 13.7 16.9 19.2 21.1
210 230
0 8.7 13.7 16.9 19.2 21.1
260 280
0 8.7 13.7 16.9 19.2 21.1
300 320
0 8.7 13.7 16.9 19.2 21.1
320 380
0 8.7 13.7 16.9 19.2 21.1
380 400
0 8.4 13.4 16.5 18.8 20.6
420 460
0 8.3 13.3 16.4 18.7 20.5
460 500
0 8.3 13.3 16.4 18.7 20.5
500 550
0 8.3 13.3 16.4 18.7 20.5
600 650
0 8.3 13.3 16.4 18.7 20.5
Note: The values are dB(A) (pressure level), in open field conditions on reflecticting surface (directivity factor Q=2)
